Are you considering replacing your casement windows but aren't quite ready to call a contractor? Measuring your windows can be a great first step in the window shopping process. In this post, we'll discuss the importance of accurate measurements for replacement casement windows and provide a brief overview of the steps involved in measuring them.
Before you start measuring your casement windows for replacement, it's important to understand the different parts that make up the window frame. Here are the key components you should know:
● Jamb: The jamb refers to the pieces that form the top and vertical sides of your window frame. They're the parts that run along the sides and top of your window opening.
● Head (or head jamb): This is the horizontal piece at the very top of your window frame. It's the part that sits above the window and connects the two side jambs.
● Sill: The sill is the horizontal piece at the bottom of your window frame. It's the part that you might place plants or other decorations on, and it helps to shed water away from the window.
Understanding these basic parts will help you when it comes time to measure your casement windows for replacement. In the next section, we'll go over the tools you'll need to get accurate measurements.
Before you start measuring your casement windows for replacement, make sure you have these essential tools on hand:
● Tape measure: A good quality tape measure is a must-have for accurate measurements. Look for one that's at least 25 feet long and has a locking mechanism to keep it in place while you measure.
● Pen and paper: You'll need something to record your measurements with. A pen and paper are simple and reliable, but you can also use a smartphone app if you prefer.
● Helper: While not strictly necessary, having a helper can make measuring larger windows much easier. They can hold one end of the tape measure while you hold the other, ensuring a straight and accurate measurement.
● Measurement guides: Many window manufacturers offer measurement guides on their websites. These can be incredibly helpful, as they provide specific instructions for measuring their particular windows. Be sure to download or print out the guide for your specific window brand and model.
With these tools ready to go, you'll be well-prepared to measure your casement windows accurately. In the next section, we'll walk through the step-by-step process of measuring your windows for replacement.
Before you start measuring your casement windows for replacement, it's crucial to check if they're square. Here's how to do it:
1. Measure diagonally from the upper left corner to the lower right corner of your window frame. Write down this measurement.
2. Now, measure diagonally from the upper right corner to the lower left corner. Record this measurement as well.
3. Compare the two diagonal measurements. If they're within 1/8 inch of each other, your window is square.
Why is it important for your casement windows to be square? Well, if they're not, it can cause problems when installing your replacement windows. The new windows may not fit properly, leading to issues with opening, closing, and sealing.
If you find that your windows are out of square, don't worry. A professional window installer can often make adjustments during the installation process to ensure a proper fit. However, it's still important to note this when measuring for your replacement windows.
In the next section, we'll move on to measuring the width of your casement windows.
Now that you've checked if your casement windows are square, it's time to measure the width. Here's how to do it:
1. Open your casement window so you can access the jambs on either side.
2. Place your tape measure against the left jamb at the center of the window. Extend it straight across to the right jamb.
3. Measure to the nearest 1/8 inch and record this measurement. This is the width of your casement window.
4. If your measurement falls between two 1/8 inch marks, round down to the nearest 1/8 inch. This will ensure your replacement window fits properly.
Location | Measurement |
Center | 24 1/4 inches |
It's important to measure at the center of the window because the width may vary slightly at the top and bottom. By measuring in the middle, you'll get the most accurate representation of your window's width.
If you have multiple casement windows to measure, be sure to record the width for each one individually. Even windows that look identical can have slight variations in size.
In the next section, we'll cover how to measure the height of your casement windows.
With the width measurement recorded, it's time to measure the height of your casement window. Follow these steps:
1. Start at the center of the window and place your tape measure against the head jamb at the top of the window frame.
2. Extend the tape measure straight down to the sill at the bottom of the window frame.
3. Measure to the nearest 1/8 inch and record this measurement. This is the height of your casement window.
Just like with the width measurement, it's important to measure the height at the center of the window. The height may vary slightly at the left and right sides, so measuring in the middle will give you the most accurate result.
If you have multiple casement windows, don't assume they're all the same height. Measure each one individually and record the measurements separately. This will ensure you order the correct size replacement windows for each opening.
In the next section, we'll discuss why it's important to double-check your measurements before ordering your replacement casement windows.
Before you order your replacement casement windows, it's crucial to double-check your measurements. Here's what you should do:
1. Repeat steps 2 and 3 from the previous sections to measure the width and height again. This will help ensure your initial measurements were accurate.
2. Measure the width at the top, middle, and bottom of the window frame. Record the smallest of these three measurements.
3. Measure the height at the left, center, and right of the window frame. Again, record the smallest of these three measurements.
By measuring in multiple locations, you can account for any slight variations in the window frame. Using the smallest measurement for each dimension ensures your replacement windows will fit properly.
Location | Width | Height |
Top | 24 1/4 inches | - |
Middle | 24 1/8 inches | 36 1/2 inches |
Bottom | 24 1/8 inches | - |
Left | - | 36 1/2 inches |
Right | - | 36 3/8 inches |
In this example, the smallest width measurement is 24 1/8 inches, and the smallest height measurement is 36 3/8 inches. These are the dimensions you would use when ordering your replacement casement windows.
Taking the time to double-check your measurements may seem tedious, but it's an essential step in ensuring your replacement windows fit perfectly. In the next section, we'll discuss some additional considerations to keep in mind when measuring your casement windows.
While measuring the width and height of your casement windows is the most critical aspect of the process, there are a few additional factors to keep in mind:
1. Note the type of windows in your home: In addition to casement windows, you may have other types of windows, such as double-hung, picture, or awning windows. Make a list of the different window types you have, as this information will be helpful when ordering replacement windows.
2. Record the number of windows you have in your home: Count the total number of windows in your home, as well as the number of each type of window. This will ensure you don't forget any windows when placing your order.
3. Inspect windows for any damage or issues: While measuring your casement windows, take the opportunity to inspect them for any signs of damage, such as cracks, rot, or warping. Make note of any issues you find, as this can help you determine if you need to replace the entire window frame or just the sash.
Window Type | Quantity | Damage/Issues |
Casement | 4 | Minor warping on one window |
Double-hung | 6 | None |
Picture | 2 | Cracked glass on one window |
By considering these additional factors, you'll be better prepared when it comes time to order your replacement casement windows. You'll have a clear understanding of how many windows you need, what types of windows you have, and any specific issues that need to be addressed.
In the next section, we'll discuss some important considerations to keep in mind when replacing your casement windows, including the differences between insert and full-frame replacement windows.
When replacing your casement windows, there are a few important factors to consider:
One of the first decisions you'll need to make is whether to use insert replacement windows or full-frame replacement windows.
● They fit into your existing window frame, which can save time and money on installation.
● They preserve your home's exterior appearance, as the existing trim remains in place.
● They're a good choice if your current window frames are in good condition.
● Your existing window frames must be square and in good condition.
● You need a minimum jamb depth of 3 ¼ inches to accommodate the new window.
If your window frames are damaged or don't meet the requirements for insert replacement windows, you'll need to use full-frame replacement windows instead. These involve removing the entire window frame and installing a new one.
Another important consideration when replacing your casement windows is local building code requirements. These can vary depending on where you live, but some common requirements include:
● Tempered glass requirements: In certain locations, such as bathrooms or near doors, windows may be required to use tempered glass for safety reasons.
● Egress requirements: Bedrooms typically require windows that meet certain size requirements to allow for emergency escape and rescue.
● Performance criteria for specific locations: In coastal areas or other regions prone to severe weather, windows may need to meet specific performance criteria for wind resistance or impact protection.
Before purchasing your replacement casement windows, be sure to check with your local building department to ensure they meet all necessary code requirements. Your window installer should also be familiar with these requirements and can help guide you in selecting the appropriate windows for your home.
Now that you've measured your casement windows and considered the various factors involved in replacing them, it's time to start shopping. Here are some of the best places to buy replacement casement windows:
1. Local home improvement stores: Large retailers like The Home Depot or Lowe's often carry a wide selection of replacement windows, including casement styles. They can be a convenient option, as you can see the windows in person and take them home the same day.
2. Building supplies dealers: Specialty building supplies dealers may have a more extensive selection of replacement windows than home improvement stores. They can also provide expert advice on selecting the best windows for your home.
3. Online retailers: There are many online retailers that sell replacement casement windows, such as Amazon or Wayfair. Shopping online can be convenient, but be sure to double-check your measurements and read reviews before making a purchase.
4. Manufacturer's "Where to Buy" tool: Many window manufacturers have a "Where to Buy" tool on their website that allows you to find local retailers that carry their products. This can be a good way to find a retailer in your area that specializes in the specific brand of windows you're interested in.
Retailer Type | Pros | Cons |
Home Improvement Stores | Convenient, can see windows in person | Limited selection |
Building Supplies Dealers | Extensive selection, expert advice | May be more expensive |
Online Retailers | Convenient, wide selection | Can't see windows in person, shipping costs |
Manufacturer's "Where to Buy" Tool | Finds local retailers specializing in specific brands | May not show all options in your area |
Ultimately, the best place to buy your replacement casement windows will depend on your specific needs and preferences. It's a good idea to shop around and compare prices and selection from multiple retailers before making a decision.
When it comes to installing your replacement casement windows, you have two main options: doing it yourself (DIY) or hiring a professional contractor. Let's explore the pros and cons of each approach.
Pros | Cons |
Can save money on labor costs | Requires time, skills, and tools |
Allows for a sense of accomplishment | Risk of improper installation and damage |
Provides a learning opportunity | May void the window warranty |
If you're handy and have experience with home improvement projects, DIY installation can be a cost-effective option. However, it's important to carefully consider your skills and the potential risks before taking on this project.
There are several situations where hiring a professional contractor is the best choice:
● If you're not confident in your ability to install the windows correctly
● If you don't have the necessary tools or experience
● If your windows are large, complex, or require structural changes
● If you want to ensure the windows are installed according to the manufacturer's specifications and local building codes
Professional contractors have the experience, skills, and tools to ensure your replacement casement windows are installed correctly and efficiently.
Many window manufacturers offer a certified contractor program. These programs provide training and certification to contractors who meet specific standards for installation quality and customer service.
To find a certified contractor in your area, visit the window manufacturer's website and look for a "Find a Contractor" or "Certified Installer" tool. You can enter your location to find certified contractors near you.
By choosing a certified contractor, you can have peace of mind knowing your replacement casement windows will be installed by a professional who adheres to the manufacturer's guidelines and industry best practices.
Measuring your casement windows accurately is crucial when replacing them. By following the step-by-step guide provided in this article, you can ensure a proper fit for your new windows.
Before purchasing replacement casement windows, consider factors such as insert vs. full-frame installation, local building codes, and whether to DIY or hire a professional.
For more information, consult manufacturer's measuring guides and installation resources. With careful planning and accurate measurements, you can successfully replace your casement windows and enjoy a more comfortable, energy-efficient home.
Insert replacement windows fit into your existing window frame, while full-frame replacement windows involve removing the entire window frame and installing a new one.
If you have the necessary skills, tools, and experience, you may be able to replace your casement windows yourself. However, if you're unsure or your windows require structural changes, it's best to hire a professional.
Many window manufacturers offer a certified contractor program. Visit the manufacturer's website and look for a "Find a Contractor" or "Certified Installer" tool to locate certified contractors in your area.
If your measurements vary, use the smallest measurement for each dimension (width and height) to ensure your replacement windows will fit properly.
The installation time depends on various factors, such as the number of windows, their size, and the condition of the existing frames. A professional contractor can typically install a single window in a few hours, but a whole-house project may take several days.
Yes, local building codes may have requirements for factors such as tempered glass, egress, and performance criteria. Check with your local building department or a professional contractor to ensure compliance.
Yes, you can replace your casement windows with a different style, such as double-hung or sliding windows. However, this may require more extensive modifications to the window opening and framing.
