Raws li lub chaw tsim khoom lag luam sliding patio qhov rooj, DERCHI muab cov ntaub ntawv pov thawj aluminium rau cov chaw nyob thiab kev lag luam thoob ntiaj teb. Peb qhov chaw 70,000 sqm thiab cov ntawv pov thawj thoob ntiaj teb txhais tau tias peb tuaj yeem xa cov nplai rau B2B cov neeg siv khoom.
- 300,000 sqm txhua xyoo muaj peev xwm txhawb nqa los ntawm 8 automated ntau lawm kab.
- NFRC, CE, AS2047, thiab AAMA ntawv pov thawj rau kev ua raws cai thoob ntiaj teb.
- Kev cai qhov ntau thiab tsawg, glazing, thiab tiav kom phim qhov project specifications.
Khoom Paub meej
Sliding patio qhov rooj manufacturers zoo li DERCHI nqis peev ntau hauv kev ua haujlwm thermal thiab huab cua tsis kam. 143 thiab 135F Series siv 6063-T5 thermally tawg txhuas nrog ob chav tempered iav thiab argon sau, ua tiav U-tus nqi ntawm 2.5 W / (m²·K). Patented los tiv thaiv typhoon lub log sab sauv thiab zais ntsug ntsug muab txog 4.5 kPa cua tsis kam thiab 350 Pa dej nruj, tiv thaiv cov ntug dej hiav txwv thiab cov tsev siab siab.
Tsis zoo li cov qhov rooj dav dav, peb cov khoom tsim ua raws li 168 tus qauv txheej txheem nrog rau 38-taw tes ntsuas lub cev ntawm txhua chav. Qhov kev sib xws no txhawb nqa ntau qhov kev txiav txim thaum tso cov vaj huam sib luag loj (txog 16 ko taw), kev sib koom ua ke automation, thiab kev teeb tsa ntau yam. Cov neeg yuav khoom tau txais cov ntaub ntawv pov thawj zoo, ua kom yooj yim rau kev yuav khoom rau kev loj hlob.
Khoom nta
Insulated Ncej Kev Tsim Kho: Polyamide-reinforced 6063-T5 profiles cais sab hauv thiab sab nrauv aluminium, txiav cov cua sov hloov los pab kom tau raws li cov cai ntawm lub zog.
Typhoon-Ready Wind Resistance: Patented anti-oscillation rollers thiab reinforced interlocks tuav 4.5 kPa loads, haum rau cov cheeb tsam nag xob nag cua.
Multi-Point Locking Security: Plaub-sided rau-point lock systems koom nrog ntau tus nuv bolts rau kev quab yuam-nkag mus rau hauv pem teb daim ntaub ntawv.
Superior Water Management: Hidden vertical floor drains with a patented design achieved 350 Pa dej nruj, tiv thaiv to thaum los nag hnyav.
Acoustic Comfort: Argon-filled ob chav glazing nrog PVDF sov-ntug spacers txo cov suab nrov sab nraud txog li 32 dB, zoo haum rau cov suab nrov hauv nroog.
Loj-Qhib Muaj Peev Xwm: Cov vaj huam sib luag tuaj yeem ncav cuag 5 txog 16 ko taw dav thiab txhawb nqa txog li 1000 kg, nrog rau sab saum toj-dhau lossis hauv qab-rolling configurations.
Customizable Styles
Kev xaiv iav: Ob chav lossis triple glazing nrog Low-E txheej, tinted, laminated, lossis argon-filled units kom tau raws li kev xav tau ntawm lub zog thiab kev ruaj ntseg.
Ncej Finishes: hmoov txheej, PVDF fluorocarbon, anodized, los yog ntoo-grain hloov mus rau architectural sib xws.
Loj & Configurations: tsau panels, ib leeg los yog ob sliders, multi-track stacking; qhib mus txog 16 ft dav thiab 12 ft siab.
Track Style: Hauv qab-dov rau kev teeb tsa ncaj nraim lossis sab saum toj-duab rau kev hloov pauv hauv pem teb.
Xim Matching: Kev cai RAL lossis Pantone xim muaj raws li qhov kev thov, ua kom muaj kev sib koom ua ke ntawm facade.
Kho vajtse Accessories
Silent Rollers: Plaub-log carriages nrog stainless hlau bearings muab kev ua haujlwm du nyob rau hauv lub vaj huam sib luag hnyav.
Multi-Point Hook Locks: Tuag-cam khwb cia txhuas tuav nrog kev xaiv plaub-sided rau-point xauv rau kev ruaj ntseg ntxiv.
Anti-Typhoon Upper Wheels: Patented design tiv thaiv vaj huam sib luag disengagement thaum muaj cua daj cua dub.
Nkaum Ntsug Drains: Muab zais rau hauv qab txoj kab tsheb ciav hlau, qhov no patented system channel dej tsis cuam tshuam cov kab huv.
Tau tshaj Hardware Hom: Kev koom ua ke nrog WEHAG, HOPO, PAG, VBH, thiab lwm tus muab cov neeg yuav khoom yooj yim.
Basic Parameters
Yam khoom ua haujlwm | Cov ntaub ntawv muaj | Cov Ntawv Sau |
|---|---|---|
Thermal rwb thaiv tsev (U-tus nqi) | 2.5 W / (m²·K) nrog 5 + 27A + 5 argon-filled units | U-tus nqi nyob ntawm iav configuration; NFRC-rated qhov tseem ceeb muaj rau kev ua qauv hluav taws xob. |
Cua Siab Resistance | 4.5 kPa (Class 8) rau cov qauv xaiv | Paub meej tias yuav tsum tau ua ib qhov siab ntawm lub tsev; upgraded kev xaiv rau high-rise muaj. |
Dej nruj | 350 pab | Haum rau huab cua monsoon; txheeb xyuas qhov kev ua tau zoo nyob rau hauv ib cheeb tsam tsev lis dej num. |
Huab cua nruj | 3.0 m³ / (m·h) (qib 7) | Rau cov huab cua txias, xav txog kev txhim kho cov pob khoom gasket kom txo tau cov infiltration. |
Suab rwb thaiv tsev | 32dB ib | STC 40+ ua tiav nrog laminated iav; qhia qhov project nrov theem thaum xaj. |
Khoom Specifications
Series | Ncej Khoom | iav | Max Vaj Huam Sib Luag | U-Tus nqi | Cua ntsuas | Daim ntawv pov thawj |
|---|---|---|---|---|---|---|
143 | 6063-T5 2.2 hli | 5 + 27A + 5 tempered | Hu rau kom paub meej | 2.5 | 4.5 kPa ua | AWM, CE |
135F | 6063-T5 2.2 hli | 5 + 27A + 5 argon | Hu rau kom paub meej | 2.5 | 4.5 kPa ua | CE, AW |
Q5 | 2.2 hli / 1.8mm | 5+ 27A+ 5 | Confirm ib qhov project | 2.5 (zeeg) | Hu rau | NFRC, AS 2047 |
q9 ua | Slim bearing aluminium | 8 + 21A + 8 los yog qauv | Mus txog 12' qhov siab | Hu rau | Hu rau | Hu rau |
q15 ua | Kev cai hnyav aluminium | Hu rau | 16' dav, 1000 kg | Hu rau | Hu rau | Hu rau kev lag luam |
Qhov zoo
Scaled Manufacturing: 70,000 sqm Hoobkas nrog 8 automated kab thiab 600+ neeg ua hauj lwm xa 300,000 sqm txhua xyoo tso zis.
Daim ntawv pov thawj Portfolio: Cov khoom muaj NFRC, CE, AS2047, thiab AAMA cov cim, ua kom yooj yim rau kev ua lag luam ntau.
Kev them nyiaj yug engineering: Kev simulation hauv tsev thiab kev ntsuas huab cua pab txhim kho qhov rooj teeb tsa rau txhua qhov haujlwm.
10-Xyoo Warranty: Profiles thiab iav npog rau 10 xyoo (15 rau fluorocarbon), kho vajtse 5-10 xyoo, nrog 24/7 tom qab-muag.
Export Ntim: ISPM 15 crates, UV-tiv thaiv films, thiab desiccants tiv thaiv cov khoom xa tuaj; FOB, CIF, thiab DDP cov nqe lus muaj.
Daim ntawv thov Scenario
Chav tsev: Qhov chaw txuag cov sliders nrog thav duab slim txuas balconies thaum Low-E iav tswj cov cua sov thiab cov suab nrov rau hauv nroog loj.
Chaw Ua Haujlwm Hauv Tsev: Lub qhov rooj patio coj nruab hnub nrig thiab huab cua ntshiab; insulated thav duab thiab acoustic glazing tuav ib qho chaw xis nyob, tsom mus ua haujlwm.
Lub tsev so: ntsiag to, ruaj ntseg zawv zawg qhov rooj nrog ntau lub ntsiab lus xauv rau cov qhua thiab cov chaw hauv pas dej ua ke; kev cai tiav ua ke nrog kev tos txais lub npe.
Chaw Ua Haujlwm Lub Tsev: Tsis siv neeg loj-hom sliders tuav cov tsheb hnyav, txhawb lub zog lub hom phiaj, thiab lees txais kev nkag mus rau kev sib koom ua ke.
Sab nraum zoov: Rau cov terraces npog, paub meej tias huab cua tiv thaiv nrog tus muag khoom. Corrosion-resistant aluminium thiab cov kua dej kom zoo tiv thaiv cov ntsiab lus.
Lub tsev nyob: Ua raws li U-tus nqi thiab huab cua nruj nyob thoob plaws ntau lub tsev txhim kho tag nrho cov kev ntsuas hluav taws xob thiab cov neeg xauj tsev.
Sab nrauv: Lub qhov rooj qhib tag nrho yuav tsum muaj dej nruj thiab cua tsis kam; thov kev suav cov txheej txheem raws li pawg neeg raug mob hauv zos.
Villa: Cov vaj huam sib luag saum toj kawg nkaus uas muaj qhov pom me me qhib tag nrho thaj chaw nyob rau lub vaj, ua kom haum rau qhov loj me me.
FAQ
Dab tsi ua rau DERCHI ib qho kev txhim khu kev qha zawv zawg qhov rooj chaw tsim khoom?
Peb ua haujlwm 70,000 sqm automated cog hauv Foshan thiab tuav cov ntawv pov thawj rau North America, Europe, thiab Australia. Qhov ntsuas no thiab nruj ua rau peb xa cov khoom zoo ib yam rau B2B cov haujlwm thoob ntiaj teb.
Cov qhov rooj zawv zawg no siv tau qhov twg?
Lawv haum rau thaj chaw nyob, kev lag luam, thiab kev tos txais qhua thoob ntiaj teb - los ntawm cov chav tsev balconies mus rau lub tsev so nkag thiab villas khoom kim heev. Configurations yog adaptable rau ntug hiav txwv dej thiab high-rise ib puag ncig.
Kuv tuaj yeem kho qhov ntau thiab tsawg thiab tiav?
Yog lawm, hom iav, thav duab tiav, qhov loj me, thiab kev taug qab style tuaj yeem hloov kho tau. Peb sib koom ua ke cov npe khoom kho vajtse thiab tuaj yeem tsim lub qhov rooj mus txog 16 feet dav lossis 12 feet siab.
Cov ntaub ntawv dab tsi xav tau rau kev hais lus?
Qhov project qhov chaw, qhov ntev yuav tsum tau, iav thiab cov hom phiaj ua haujlwm (U-tus nqi, cua thauj khoom), kom muaj nuj nqis, thiab cov ntawv pov thawj xav tau. Ib qho kev pom zoo feem ntau yog npaj tau hauv ob hnub ua haujlwm.
Koj puas txhawb nqa B2B cov haujlwm thiab muab cov ntaub ntawv?
Yog lawm, peb cov neeg siv khoom feem ntau yog B2B. Peb muab cov pob khoom xa tuaj, NFRC-cov ntaub ntawv tsis tuaj yeem, thiab cov ntaub ntawv pov thawj raws li tus qauv. Peb kuj tswj hwm lub Hoobkas-rau-qhov chaw logistics rau kev txiav txim ntau.
Koj lub qhov rooj muaj ntawv pov thawj dab tsi?
Ntau lub koob tuav NFRC, CE, AS2047, thiab AAMA ntawv pov thawj. Q5 series yog NFRC thiab AS2047 tau ntawv pov thawj; paub meej tias qhov twg siv rau koj tus qauv xaiv thaum lub sijhawm tshwj xeeb.
Cov neeg yuav khoom yuav tsum paub meej dab tsi ua ntej xaj?
Paub meej tias cua sov cheeb tsam, thermal kev ua tau zoo yuav tsum tau, thiab installation tej yam kev mob. Rau cov huab cua siab siab lossis huab cua huab cua, thov kev ntsuam xyuas cov qauv. Kuj qhia meej cov nqe lus shipping thiab ntim khoom xav tau.
Lub qhov rooj ntim thiab xa khoom li cas?
Cov chav nyob tau ntim rau hauv ISPM 15 fumigated crates nrog desiccants thiab UV-tiv thaiv zaj duab xis. Txheem FOB, CIF, thiab DDP cov nqe lus muaj. Lub sij hawm ua cov hmoov txhuas yog kwv yees li 55 hnub.
