Nkumushinga wabigenewe wo gukora urugi, DERCHI itanga sisitemu ya aluminiyumu yemewe kumishinga yo guturamo nubucuruzi kwisi yose. Ibikoresho byacu 70.000 sqm hamwe nimpamyabumenyi mpuzamahanga bivuze ko dushobora gutanga kubipimo kubakiriya ba B2B.
- 300.000 sqm yubushobozi bwumwaka ishyigikiwe numurongo 8 wikora.
- NFRC, CE, AS2047, na AAMA ibyemezo byo kubahiriza code yisi yose.
- Ingano yihariye, kurabagirana, no kurangiza guhuza umushinga wihariye.
Ibisobanuro birambuye
Kunyerera urugi rwa patio nka DERCHI bashora cyane mumikorere yubushyuhe no guhangana nikirere. Urukurikirane rwa 143 na 135F rukoresha 6063-T5 ya aluminiyumu yamenetse cyane hamwe nikirahure cyikubye kabiri hamwe na argon yuzuza, kugera kuri U-gaciro ka 2.5 W / (m² · K). Ipente yo kurwanya tifuni yo hejuru hamwe n'umuyoboro uhagaze uhishe bitanga umuyaga ugera kuri 4.5 kPa hamwe no gukomera kwamazi ya Pa, kurinda inyubako n’inyanja ndende.
Bitandukanye n'inzugi rusange, inganda zacu zikurikiza intambwe 168 zisanzwe hamwe n amanota 38 yumubiri kuri buri gice. Uku gushikama gushigikira ibicuruzwa byinshi mugihe wemera panne nini (kugeza kuri metero 16), guhuza automatike, hamwe nuburyo bwinshi. Abaguzi bakira inyandiko yerekana ubuziranenge, byoroshya amasoko kubikorwa binini byiterambere.
Ibiranga ibicuruzwa
Ubwubatsi bwa Frame yubatswe: Polyamide-yongerewe imbaraga 6063-T5 imyirondoro itandukanye imbere na aluminiyumu yo hanze, kugabanya ubushyuhe kugirango bifashe kubahiriza code yingufu.
Inkubi y'umuyaga Yiteguye Kurwanya Umuyaga: Patent irwanya anti-oscillation hamwe na interineti ihuza imbaraga bifata imizigo 4.5 kPa, ibereye uturere dukunze kwibasirwa ninkubi y'umuyaga.
Umutekano wo gufunga ibintu byinshi: Sisitemu enye zifata ingingo esheshatu zifunga sisitemu zifata ibyuma byinshi kugirango byinjire ku gahato-byinjira kubutaka bwa porogaramu.
Imicungire y’amazi meza: Imiyoboro ihishe ihagaritse ifite igishushanyo cya patenti igera ku mazi 350 ya Pa, ikarinda kumeneka mugihe cyimvura nyinshi.
Ihumure rya Acoustic: Argon yuzuyemo kabiri ikarishye hamwe na PVDF yubushyuhe bwo mu kirere bigabanya urusaku rwo hanze kugeza kuri 32 dB, bikwiranye n’imiterere y’urusaku rwo mu mujyi.
Ubushobozi bunini bwo gufungura: Panel irashobora kuba ifite uburebure bwa metero 5 kugeza kuri 16 kandi igashyigikira kg 1000, hamwe no kumanikwa hejuru cyangwa kumanura hasi.
Imiterere yihariye
Amahitamo y'Ibirahure: Kuzenguruka inshuro ebyiri cyangwa eshatu hamwe na E-E yuzuye, irangi, irangi, cyangwa argon yuzuye kugirango ihuze ingufu n'umutekano.
Ikadiri irangiza: Ifu ya poro, fluorocarubone ya PVDF, anodize, cyangwa ihererekanyabubasha ryibiti kugirango byubake.
Ingano & Iboneza: Ikibaho gihamye, icyerekezo kimwe cyangwa kabiri, gutondekanya inzira nyinshi; gufungura kugeza kuri metero 16 z'ubugari na 12 z'uburebure.
Inzira yuburyo: Kuzenguruka hepfo kugirango ushyire muburyo butaziguye cyangwa hejuru-umanitse hejuru yinzibacyuho.
Guhuza amabara: Koresha amabara ya RAL cyangwa Pantone aboneka ubisabwe, byemeza guhuza ibice.
Ibikoresho
Guceceka guceceka: Amagare ane yimodoka ifite ibyuma bidafite ingese bitanga imikorere myiza munsi yimitwaro iremereye.
Ifunga rya Multi-Point Hook: Gupfa-aluminiyumu ikora hamwe nimpande enye zifata ingingo esheshatu zifunga kugirango wongere umutekano.
Kurwanya Inkubi y'umuyaga yo hejuru: Igishushanyo cya patenti kirinda gucika intege mugihe cyumuyaga ukabije.
Imiyoboro ihanamye: Yihishe muri gari ya moshi yo hepfo, iyi sisitemu ya patenti ikoresha amazi idahungabanya imirongo isukuye.
Ibicuruzwa bigendanwa bihuye: Kwishyira hamwe na WEHAG, HOPO, PAG, VBH, nibindi biha abaguzi guhinduka.
Ibipimo fatizo
Ikintu Cyimikorere | Ibisobanuro Bihari | Inyandiko z'umuguzi |
|---|---|---|
Gukwirakwiza Ubushyuhe (U-agaciro) | 2.5 W / (m² · K) hamwe na 5 + 27A + 5 ibice byuzuye argon | U-agaciro biterwa n'ibirahure; Indangagaciro za NFRC ziboneka muburyo bwo kwerekana ingufu. |
Kurwanya Umuyaga | 4.5 kPa (Icyiciro cya 8) kubintu byatoranijwe | Emeza ibisabwa kuri burebure bw'inyubako; kuzamura ibiciro byo kuzamuka cyane birahari. |
Amazi meza | 350 Pa | Bikwiranye nikirere cyimvura; kugenzura imikorere irambye kuri code yinyubako. |
Ubukonje bwo mu kirere | 3.0 m³ / (m · h) (Icyiciro cya 7) | Kubihe bikonje, tekereza kubipapuro byongerewe imbaraga kugirango ugabanye kwinjira. |
Ijwi | 32 dB | STC 40+ igerwaho hamwe nikirahure cyanduye; vuga urwego rwurusaku rwumushinga mugihe utumiza. |
Ibicuruzwa byihariye
Urukurikirane | Ibikoresho | Ikirahure | Ikibaho kinini | U-Agaciro | Ikigereranyo cy'umuyaga | Icyemezo |
|---|---|---|---|---|---|---|
143 | 6063-T5 2.2mm | 5 + 27A + 5 yitonda | Menyesha amakuru arambuye | 2.5 | 4.5 kPa | AAMA, CE |
135F | 6063-T5 2.2mm | 5 + 27A + 5 argon | Menyesha amakuru arambuye | 2.5 | 4.5 kPa | CE, AAMA |
Q5 | 2.2mm / 1.8mm | 5 + 27A + 5 | Emeza umushinga | 2.5 (est.) | Twandikire | NFRC, AS2047 |
Q9 | Aluminiyumu yoroheje | 8 + 21A + 8 cyangwa imiterere | Kugera kuri 12 'uburebure | Twandikire | Twandikire | Twandikire |
Q15 | Koresha aluminiyumu iremereye | Twandikire | 16 'ubugari, kg 1000 | Twandikire | Twandikire | Menyesha ubucuruzi |
Ibyiza
Inganda nini: Uruganda rwa 70.000 sqm rufite imirongo 8 ikora kandi abakozi 600+ batanga umusaruro wa 300.000 sqm yumwaka.
Impamyabumenyi Portfolio: Ibicuruzwa bitwara NFRC, CE, AS2047, na AAMA, byoroshya kubahiriza amasoko menshi.
Inkunga yubuhanga: Imbere mu nzu kwigana imiterere no gusuzuma ikirere bifasha guhuza imiterere yumuryango kuri buri mushinga.
Garanti yimyaka 10: Umwirondoro nikirahure bitwikiriye imyaka 10 (15 kuri fluorocarubone), ibyuma byimyaka 5-10, hamwe na 24/7 nyuma yo kugurisha.
Ibicuruzwa byoherezwa mu mahanga: ISPM 15 ibisanduku, firime zirinda UV, hamwe na desiccants birinda ibicuruzwa; Amagambo ya FOB, CIF, na DDP yatanzwe.
Gusaba
Igorofa: Igikoresho cyo kuzigama umwanya hamwe na slim frame ihuza balkoni mugihe ikirahure cya E-E kigenzura ubushyuhe n urusaku rwumuhanda kumujyi uzamuka cyane.
Ibiro byo murugo: Urugi rwa patio ruzana amanywa n'umwuka mwiza; Amakadiri yiziritse hamwe na glazing acoustic agumana umwanya mwiza, wibanze kumurimo.
Hotel: Inzugi zituje, zifite umutekano zinyerera zifunze ingingo nyinshi zifasha ibyumba byabashyitsi hamwe na pisine; gakondo irangiza ihuza no kwakira abashyitsi.
Inyubako y'ibiro: Automatic nini-format ya slide ikora traffic nyinshi, igashyigikira intego zingufu, kandi ikemera guhuza ibikorwa.
Hanze: Kumaterasi yuzuye, wemeze guhangana nikirere hamwe nuwabitanze. Aluminium irwanya ruswa hamwe n'amazi meza arinda ibintu.
Inyubako yo guturamo: Guhoraho U-agaciro hamwe no gukomera kwikirere mubice byinshi biteza imbere ingufu zubaka zose hamwe nubukode bwabakode.
Inyuma: Gufungura byuzuye bisaba gukomera kwamazi no kurwanya umuyaga; saba kubara imiterere ishingiye ku byiciro byerekanwe.
Villa: Ikibaho kinini-kimanitse hejuru gifite icyerekezo gito gifungura ahantu hose gutura mu busitani, bikwiranye nubunini bwihariye.
Ibibazo
Niki gituma DERCHI yizewe kunyerera ya patio urugi?
Dukora 70.000 sqm yimashini ikora muri Foshan kandi dufite ibyemezo bya Amerika ya ruguru, Uburayi, na Ositaraliya. Iki gipimo na rigor reka dutange ubuziranenge buhoraho kumishinga ya B2B kwisi yose.
Ni hehe inzugi zinyerera zishobora gukoreshwa?
Bikwiranye n’imishinga yo guturamo, iy'ubucuruzi, no kwakira abashyitsi ku isi - kuva kuri balkoni y'amagorofa kugeza ku mahoteri yinjira muri villa. Iboneza bihuza ninyanja hamwe n’ibidukikije bizamuka.
Nshobora guhitamo ingano no kurangiza?
Nibyo, ubwoko bwikirahure, ikadiri irangiza, ingano, nuburyo bwo gukurikiranwa birashoboka. Duhuza ibirango byabigenewe kandi dushobora gukora inzugi zigera kuri metero 16 z'ubugari cyangwa uburebure bwa metero 12.
Ni ayahe makuru akenewe kugirango asubirwemo?
Ahantu umushinga, ibipimo bisabwa, ibirahuri hamwe nintego zikorwa (U-agaciro, umutwaro wumuyaga), ingano, nibisabwa byose. Icyifuzo cya tekiniki gisanzwe cyiteguye muminsi ibiri yakazi.
Waba ushyigikiye imishinga ya B2B ugatanga ibyangombwa?
Nibyo, abakiriya bacu ni B2B cyane. Dutanga ibipapuro byoherejwe, NFRC-itumizwa mu mahanga, hamwe na garanti ya garanti nkibisanzwe. Ducunga kandi ibikoresho byo muruganda-kurubuga rwibicuruzwa byinshi.
Ni ibihe byemezo imiryango yawe ifite?
Urukurikirane rutandukanye rufite ibyemezo bya NFRC, CE, AS2047, na AAMA. Urutonde Q5 ni NFRC na AS2047 byemewe; wemeze bikurikizwa kuri moderi wahisemo mugihe cyihariye.
Ni iki abaguzi bagomba kwemeza mbere yo gutumiza?
Emeza akarere k'umuyaga, ibisabwa byubushyuhe, nuburyo bwo kwishyiriraho. Kubirere birebire cyangwa bikabije, saba isuzuma ryimiterere. Sobanura kandi amagambo yo kohereza no gukenera gupakira.
Nigute inzugi zipakirwa kandi zoherejwe?
Ibice bipakiye muri ISPM 15 ibisanduku bya fumigate hamwe na desiccants na firime zirinda UV. Amagambo asanzwe ya FOB, CIF, na DDP arahari. Igihe gisanzwe cyo kuyobora ni iminsi 55.
