The 60 casement window is a DERCHI custom thermal-break aluminum made-to-size system window organized around the 60-inch (approximately 1524mm) width dimension. As a width-segment product rather than a stock standard window, it is offered in three series to match different project budget tiers.
- S9 Starlight System is the primary recommended high-end series, with S6 Star Sea and E0 Glory as alternatives.
- Large 60-inch openings are typically split into double sash, fixed+opening, or transom combinations rather than single sash.
- Configurations include extensive glass, color, hardware, and structural options for facade consistency.
Product Details
Buyers evaluating a custom 60 casement window can choose across three thermal-break aluminum series. The S9 Starlight System features a 109mm frame, 1.8mm wall thickness, and a 44/24/15mm multi-insulation strip configuration, targeting high-end residences. The S6 Star Sea System offers an 82mm frame with an invisible folding screen, while the E0 Glory Series provides a 100mm value-type frame for budget-sensitive batch engineering. All three share 5+27A+5 standard glass and identical manual performance parameters.
For a 60-inch width, single-sash outward opening is generally not recommended. Instead, the opening is typically split into double sash, triple sash, fixed center with side openings, or upper/lower fixed transom configurations. The S9 series differentiates itself with a three-seal structure, EPDM water-swelling weatherstrip, and a micro-elastic glass block that reduces glass corner stress. Buyers should confirm specific height dimensions and drawing requirements with the 60 casement window manufacturer before production.
Product Features
- Multi-Series Budget Tiering: S9, S6, and E0 series share identical manual performance parameters while covering high-end, mid-range, and budget project segments without compromise.
- Thermal-Break Technology: S9 utilizes a 44mm ultra-wide insulation strip and multi-cavity aluminum profile to reduce U-value and manage thermal transfer effectively.
- Flexible Opening Modes: All series support outward opening, top-hung, and outward-opening top-hung modes, with glass sashes opening outward to save interior space.
- Safety Hardware Ecosystem: S9 includes a child-safe handle, anti-pull angled transmission box, two-point lock, and anti-pry lock seat for enhanced security.
- Weather Resistance: EPDM water-swelling weatherstrip and multi-cavity profiles contribute to 700Pa water tightness and 5kPa wind pressure resistance manual ratings.
- Large-Opening Expertise: Sash division guidance prevents unsafe single-sash large widths, directing 60-inch openings into safe multi-sash or fixed combinations.
Customizable Styles
- Glass Options: Standard 5+27A+5 fluorocarbon hollow aluminum spacer glass; custom options include argon gas, Low-E, laminated, frosted, tinted, ultra-clear, and blinds glass.
- Frame and Structure: Choose from S9 (109mm), S6 (82mm), or E0 (100mm) thermal-break aluminum frames with multi-cavity profiles and varying insulation strip widths.
- Size Dimensions: Width is organized at 60 inches (~1524mm); height is not fixed and must be confirmed per project drawing and opening dimensions.
- Colors and Finishes: Options include Sand Gray, Black Crystal, Starry Black, White, Black Walnut, Fluorocarbon Flash Silver, plus powder coating, wood grain, and metallic finishes.
- Opening Configuration: Structural layouts include single sash, double sash, fixed+opening, side opening+center fixed, transom, asymmetric, multi-pane, and shaped window combinations.
Hardware Accessories
- Handles: S9 features a DERCHI custom child-safe handle; S6 uses a WEHAG baseless handle; optional fingerprint/password/key handles are available for S9.
- Hinges: S9 includes a 13-inch casement friction hinge and custom load-bearing hinge designed for stable outward sash operation.
- Locking System: S9 is equipped with an anti-pull angled transmission box, two-point lock, roller-sleeve lock point, and anti-pry lock seat.
- Screens: Options include 48-mesh high-transparency screen, stainless steel wire mesh, and S6's invisible folding screen sash.
- Safety Accessories: Optional guardrails and safety screens can be integrated; E0 supports 48/88 edge wrapping and upper curved arc craft.
Basic Parameters
| Performance Item | Available Information | Buyer Notes |
|---|---|---|
| Thermal Insulation | 2.0W level 6 (S9/S6/E0) | Confirm U-value units and verify if Low-E or argon gas is required to achieve target performance. |
| Wind Pressure Resistance | 5kPa level 9 (S9/S6/E0) | Verify this meets local building code requirements for your specific project location and height. |
| Water Tightness | 700Pa level 6 (S9/S6/E0) | Confirm testing standards referenced and request certified test reports for project compliance. |
| Air Tightness | 1.2 level 8 (S9/S6/E0) | Confirm specific testing standards referenced, such as GB/T 7106 or equivalent regional standards. |
| Sound Insulation | 35dB level 4 (S9/S6/E0) | Confirm glass configuration required to achieve this rating and request acoustic test reports. |
Product Specifications
| Specification | Details |
|---|---|
| Product Name | 60 Casement Window (S9/S6/E0 Series) |
| Product Type | Thermal-break aluminum made-to-size system window |
| Material | Multi-cavity thermal-break aluminum profile (1.8mm wall thickness) |
| Glass Type | 5+27A+5 fluorocarbon hollow aluminum spacer glass (standard) |
| Frame Options | S9: 109mm; S6: 82mm; E0: 100mm frame width |
| Insulation Strips | S9: 44/24/15mm; S6: 35/14.8/30mm; E0: 35/30/12mm |
| Hardware | DERCHI custom (S9), WEHAG baseless handle (S6) |
| Opening Style | Outward, top-hung, outward-opening top-hung |
| Size Range | Width: 60 inches (~1524mm); Height: To be confirmed per project |
| Sash Limits (S9) | Casement: W400-750mm H400-1500mm; Top-hung: W510-750mm H700-1500mm |
| Max Fixed Glass | 6 square meters |
| Weatherstrip | EPDM water-swelling weatherstrip (S9) |
| Colors | Sand Gray, Dark Coffee, Black Crystal, White, Indigo Gray, Mint Gold, etc. |
| Surface Finishes | Powder coating, fluorocarbon, wood grain, metallic flash silver |
| Customization | Custom sizes, colors, glass, and structural configurations available |
| Packaging | Four-layer protection: anti-scratch film, pearl cotton, waterproof film, wooden frame |
| Delivery Reference | Approximately 25-35 days (platform reference, subject to confirmation) |
| MOQ Reference | Commonly 2 square meters (confirm per order configuration) |
| Pricing Reference | Approximate internal reference only, not fixed transaction prices |
| Notes | Buyers should request actual CE/NFRC/CSA certificate copies and verify validity |
Advantages
- Multi-Series Strategy: S9, S6, and E0 series cover high-end to budget tiers with identical manual performance parameters, allowing commercial 60 casement window project budget tiering.
- Made-to-Size System: Organized around width, sash division, and application scenarios rather than generic stock windows, ensuring specific project fit and facade consistency.
- S9 Thermal Technology: Features a 44mm ultra-wide insulation strip, three-seal structure, and micro-elastic glass block to reduce U-value and relieve glass corner stress.
- Export-Ready Packaging: Four-layer strong protection including anti-scratch film, pearl cotton, waterproof outer film, and fully enclosed wooden frame for international shipping.
- Certifications Referenced: CE/NFRC/CSA and US/AU IGCC glass certifications are emphasized on the official website; buyers should request actual certificate copies to verify applicability.
Application Scenarios
- Apartment: In apartment complexes, the 60-inch width can be configured as double-sash or fixed+opening combinations to provide ventilation and natural light without occupying interior space.
- Home Office: Top-hung or outward-opening top-hung modes allow controlled airflow during working hours, maintaining a quiet environment supported by 35dB sound insulation.
- Hotel: High-end S9 series with custom colors and safety hardware matches hospitality design requirements while offering stable outward operation for guest rooms.
- Office Building: Commercial 60 casement window configurations can be standardized across multiple floors, utilizing multi-pane window wall combinations for consistent facades.
- Outdoor: For outdoor-facing installations, buyers should confirm weather resistance, water tightness, and wind pressure parameters to ensure structural integrity against local conditions.
- Residential Building: E0 Glory series supports batch residential applications requiring thermal-break double glazing, offering a value-type solution for budget-sensitive new-build projects.
- Exterior: When used on exterior continuous facades, confirm surface finish durability, installation conditions, and sealing structure to manage long-term exposure effectively.
- Villa: S9 Starlight System accommodates large-opening multi-sash combinations and shaped windows like bay or trapezoidal designs for modern villa architecture.
Inquiry Guidance
To request a quote, please share your project location, required size, quantity, preferred frame color, glass type, hardware requirements, and drawings or reference photos if available.
FAQ
How do I choose between the S9, S6, and E0 series for a 60-inch width?
Select S9 for high-end projects needing 44mm ultra-wide insulation strips; S6 for mid-range projects wanting invisible folding screens; E0 for budget-sensitive batch engineering. All share identical manual performance parameters.
Is the height fixed for the 60-inch width product?
Height is not a fixed value. The 60 casement window is a made-to-size system, so buyers must provide required height or opening dimensions and project drawings for custom production confirmation.
Can the 60-inch width be a single-sash outward opening window?
Single-sash outward opening is generally not recommended for 60-inch large widths. Openings are typically split into double sash, triple sash, fixed center with side openings, or upper/lower fixed transom combinations.
What information is needed to get a quote from a 60 casement window supplier?
Provide quantity, destination port or door-to-door address, drawings, series selection, glass/color/hardware configuration, and packaging requirements. This ensures accurate pricing rather than relying on internal reference ranges.
Are CE/NFRC/CSA certifications available for this product?
CE/NFRC/CSA and US/AU IGCC glass certifications are referenced on the official website. Buyers should request actual certificate copies and verify validity and applicability to their specific product configuration.
What is the Minimum Order Quantity (MOQ) and delivery time?
Platform data shows a common MOQ of 2 square meters and approximately 25-35 days delivery. These are subject to confirmation and may vary based on specific order configuration and destination.
Are grilles, grids, or divided-lite patterns available?
Availability of grilles, grids, or divided-lite patterns should be confirmed with the supplier directly. Buyers should also request installation instructions, jamb options, and mounting condition guidance before ordering.
