W-G41 Translating Sealed Window

Performance Advantages

Dual-Function Application Flexibility

The series supports deployment as both windows and doors, enabling flexible installation planning across different building zones such as exterior facades, commercial storefronts and interior partition areas. This design accommodates varied project layouts without requiring separate product systems.

Diverse Opening Configurations

Multiple opening patterns are available, including six standard configurations and custom fixed-operable combinations. These options match different ventilation demands and access requirements for commercial buildings, high-rise residences and hospitality projects.

Space-Optimized Translating Structure

The side-press translating operation eliminates the interior swing radius required by traditional inward-opening windows. This structure reduces interior space occupation, making it suitable for rooms with limited indoor clearance and compact architectural layouts.

Improved Sealing and Weather Resistance

Compared with conventional sliding windows, this series adopts multi-point compression sealing technology. It achieves 700Pa water tightness and 1.2 m³/(m·h) air tightness, delivering upgraded weather performance for coastal regions and areas with heavy rainfall.

Wind-Resistant Safety Design

The translating structure removes the outward-swinging sash hazard present in outward-opening windows. With a 5KPa wind pressure resistance rating (Class 9 per GB/T 7106 standards), the series supports installation in high-rise buildings and regions prone to strong winds.
