A 24x30 casement window offers a practical ventilation solution for residential and commercial builds, combining a 6063-T5 aluminum frame with smooth hand-crank operation. This made-to-size crank out window adapts to diverse project requirements.
- Nominal size 24 in x 30 in (610 x 762 mm)
- Available in 72 mm, 86 mm, or 100 mm frame depths
- Double tempered glass with EPDM rubber sealing
- Suitable for importers needing reliable aluminum casement window products
Product Details
The 24x30 casement window is built using a 6063-T5 aluminum profile with a confirmed 1.4 mm wall thickness, paired with EPDM rubber strips to minimize air and water infiltration. Buyers can select from frame depths of 72 mm, 86 mm, or 100 mm depending on the required glass configuration and structural demands, making it a versatile choice for both residential and commercial complexes.
Operation relies on a hand crank mechanism, allowing users to control airflow without reaching through the opening. The inclusion of double tempered glass provides impact resistance, while the made-to-size production approach ensures each unit fits specific rough openings. Buyers should confirm final layout and crank side during the drawing stage to match project schedules.
Product Features
6063-T5 Aluminum Frame: Provides structural integrity and corrosion resistance for long-term exterior exposure in varied climates.
Hand-Crank Operation: Allows effortless ventilation control, making this crank out window accessible for hard-to-reach areas like over sinks.
EPDM Rubber Sealing: Compresses tightly between sash and frame to reduce drafts and help block moisture intrusion during rain.
Double Tempered Glass: Enhances occupant safety by resisting breakage, holding shattered pieces together upon impact.
Multiple Frame Depths: Offers 72, 86, or 100 mm options to accommodate different glass packages and thermal performance targets.
Made-to-Size Production: Manufactured to specific project dimensions, reducing on-site trimming and accelerating installation timelines.
Customizable Styles
Glass Configuration: Choose between 5+27A+5 mm or 5+15A+5 mm double tempered glass based on the selected series and thermal requirements.
Frame Depth: Select 72 mm, 86 mm, or 100 mm profiles to match structural needs and local energy code compliance.
Size and Layout: Beyond single sash, options include double sash, fixed and operable combinations, or three-segment configurations.
Color and Finish: Standard choices include Pearl White, Quartz Gray, and Black Walnut wood grain; custom PVDF colors are available with upcharges.
Opening Configuration: Specify left or right hand crank operation, and explore awning or fixed plus operable composite styles.
Hardware Accessories
Hand Crank Mechanism: Choose American hand crank for WY-72 or Australian hanging hand crank for WY-86 and WY-100 series.
Switch Lock Seats: Multi-point switch lock seats secure the WY-72, while single-point options secure the WY-86 and WY-100.
Casement Limiters: Optional simple or safety limiters control the opening angle to manage ventilation and prevent wind damage.
Safety Fences: Fixed or opening safety fences can be integrated, subject to series compatibility and project security requirements.
Handle Upgrades: Various handle upgrade options are available to match interior aesthetics and user accessibility preferences.
Basic Parameters
Performance Item | Available Information | Buyer Notes |
|---|---|---|
Thermal Insulation | U-Factor: 0.39 | Confirm if this meets local energy code requirements; consider argon or warm-edge upgrades. |
Wind Pressure Resistance | 5 KPa | Confirm sufficiency for local wind load code and specific building height. |
Water Tightness | 350 Pa | Verify this rating meets local weather resistance requirements for the project location. |
Air Tightness | 4.5 m3/(m.h) | Verify the applicable performance rating class required in the target market. |
Sound Insulation | 30 dB | May be insufficient for high-noise environments; consider laminated glass upgrades. |
Product Specifications
Specification | Details |
|---|---|
Product Name | 24x30 Casement Window |
Product Type | Cranked-out / Hand-crank operated casement window |
Material | 6063-T5 aluminum profile |
Nominal Size | 24 x 30 in (610 x 762 mm) |
Approximate Area | 0.46 m2 |
Profile Thickness | 1.4 mm |
Frame Depth Options | 72 mm / 86 mm / 100 mm |
Glass Type | Double tempered glass |
Glass Thickness | 5+27A+5 mm (WY-72/100) or 5+15A+5 mm (WY-86) |
Sealing | EPDM rubber strip |
Opening Panel Range | W 450-800 mm x H 600-1500 mm |
Opening Style | Flat opening / hanging up, hand-crank |
Application | Residential, commercial, villas, apartments |
Customization | Made-to-size; colors, glass, and hardware configurable |
Notes | Final series selection and rough opening subject to drawing confirmation |
Advantages
Made-to-Size Production: Each aluminum casement window is manufactured to exact project dimensions, ensuring a precise fit for varied rough openings.
Flexible Frame Options: Three frame depth choices allow buyers to balance structural requirements, glass packages, and cost efficiency effectively.
Export-Ready Packaging: Wooden-frame packaging with PE films and air bags protects units against sea water and transit damage during international freight.
Optional Safety Components: Buyers can integrate safety fences, anti-theft screens, or King Kong mesh to meet specific building security standards.
Hand-Crank Convenience: The crank out window mechanism provides smooth operation, making ventilation management easy for occupants of all abilities.
Application Scenarios
Apartment: Compact urban units benefit from the hand-crank mechanism, allowing residents to ventilate tight spaces without obstructing interior walkways or furniture.
Home Office: Controlled airflow reduces indoor humidity and stuffiness during long work hours, while double tempered glass helps maintain a quieter working environment.
Hotel: Guest rooms require reliable ventilation and security; the multi-point lock and optional safety screens provide peace of mind for hospitality operators.
Office Building: Commercial facades can integrate these made-to-size units to standardize window schedules while meeting specific thermal and air leakage targets.
Outdoor: For outdoor-facing enclosures or balconies, buyers should confirm water tightness and wind resistance against local weather conditions before finalizing specifications.
Residential Building: Kitchens and bathrooms often need effective moisture exhaust; the crank operation allows precise control over ventilation rates in these high-humidity rooms.
Exterior: When installed on exterior facades, the 6063-T5 aluminum frame withstands exposure, though surface finish and installation details must be verified for local climates.
Villa: Bedrooms and living rooms in villas utilize the 24x30 casement window for its clean aesthetics and ability to channel fresh air deep into the living space.
Inquiry Guidance
To request a quote, please share your project location, required size, quantity, preferred frame color, glass type, hardware requirements, and drawings or reference photos if available.
FAQ
What information is needed for a quote?
Please share sizes, quantity, project location, glass type, frame finish, hardware needs and drawings so the 24x30 casement window configuration can be reviewed.
Can it be customized?
Size, color, glass and hardware options can usually be discussed according to project drawings and confirmed production requirements.
Where can it be used?
It can be considered for residential, commercial and project entry applications after confirming installation conditions and performance needs.
What should buyers confirm before ordering?
Confirm dimensions, finish, glass, hardware, wall conditions, packaging, shipping requirements and any local compliance documents before production.
Are technical documents available?
Technical drawings, configuration details or documentation should be confirmed with the supplier according to the selected project requirements.
