The aluminum swing door is configurable for left-hand outswing operation, suited to interior partitioning and sheltered entryways. Its 6063-T5 frame, dual-pane or single tempered glass options, and EPDM weather seals deliver dependable performance.
- Aluminum Construction: 6063-T5 extrusion with 1.45mm frame and 1.2mm leaf thickness.
- Glazing Choices: 5+12A+5 double glazing (U-factor 0.39) or 8mm tempered single glass.
- Swing Direction: Factory-set left-hand outswing; right-hand and inswing also available.
- Adjustable Dimensions: Opening panel widths from 600–850 mm, heights from 1800–2500 mm.
Product Details
The’s structure is built around a 54mm-wide 6063-T5 frame (1.45mm thick) paired with a 1.2mm-thick door leaf. The leaf’s glazed panel is assembled using a gluing process, while fixed sections use a press-fit glazing bead — both methods ensure consistent bonding and clean sightlines. EPDM rubber profiles provide continuous air and water sealing. With the 5+12A+5 double glazing, thermal performance reaches U-0.39 and SHGC 0.25, making the door suitable for conditioned interior spaces. A matched set of DERCHI custom handle and hinges supports the outswing action and is verifiable before production.
When configured for left-hand outswing, the door can help preserve floor area in tight corridors or covered entries. Its customizable dimensions, two glazing options, and coordinated hardware offer a precise fit for project-specific specifications — all confirmable at order stage.
Product Features
Order-Defined Handing: Swing direction and hand (left or right, inward or outward) are factory set to match your door schedule, eliminating site adjustments.
Low-Energy Glass: The 5-12A-5 insulated unit delivers U-0.39 and SHGC 0.25, helping maintain steady temperatures in air-conditioned zones.
37 dB Sound Reduction: Cuts noise transfer between rooms — useful for studies, bedrooms, and office partitions.
Corrosion-Resistant Frame: 6063-T5 aluminum stays dimensionally stable in indoor environments, ensuring long service life.
Cut-to-Size Fabrication: Opening panels are made to your exact width (600–850 mm) and height (1800–2500 mm), fitting architectural openings without alterations.
EPDM Weather Seals: Integrated rubber strips contribute to air tightness of 5 m³/(m²·h) and water tightness of 300 Pa, minimizing drafts and moisture ingress.
Customizable Styles
Glass Configuration: Opt for 5+12A+5 double glazing for energy control, or 8mm tempered single glass for a lighter appearance.
Frame Finish: Standard powder-coated or anodized; custom RAL colors on request — provide a color sample for pre-production matching.
Dimensional Adjustability: Fabrication range covers widths of 600–850 mm and heights of 1800–2500 mm for the active panel; fixed panels sized per project drawings.
Handing & Swing: Left- or right-hand, outswing or inswing — the order-defined setting prevents installation guesswork.
Thickness & Profile: The 54mm base frame can be extended with supplementary profiles for thicker walls; share wall build-up details for compatibility.
Hardware Accessories
DERCHI Custom Handle: Ergonomically contoured; lever style and finish can be aligned with your project hardware schedule.
DERCHI Customized Hinges: Smooth-action hinges designed for consistent outswing movement; load ratings and technical drawings available on request.
Multi-Point Lock (Optional): Additional locking points can be integrated for higher security — confirm configuration during quotation.
Low-Profile Threshold & EPDM Seal: Helps maintain air/water performance at level-entry conditions; suitable for barrier-free transitions.
Door Closer/Stopper: Surface-mounted closers or stoppers can be supplied as accessory items to meet fire or accessibility requirements.
Basic Parameters
Performance Item | Available Information | Buyer Notes |
|---|---|---|
Thermal Insulation | U‑Factor 0.39 | Obtain a test report for your specific glazing and size combination to confirm local code compliance. |
Wind Pressure Resistance | 3 KPa | Request the test certificate and verify that the tested panel size matches your project opening. |
Water Tightness | 300 Pa | Discuss whether 300 Pa meets your climate zone requirements and what threshold options are available. |
Air Tightness | 5 m³/(m²·h) | Confirm which European or local standard the value was measured under with your supplier. |
Sound Insulation | 37 dB | Verify that the acoustic rating applies to your selected glass type; request additional lab data if needed. |
Product Specifications
Item | Specification | Notes |
|---|---|---|
Product Name | P50 Aluminum Swing Door | |
Product Type | Aluminum alloy glass swing door | Outswing/Inswing, Left/Right |
Profile Material | 6063-T5 Aluminum | Frame: 1.45mm; Leaf: 1.2mm |
Frame Width | 54 mm | |
Glass Options | 5+12A+5 double / 8mm tempered single | |
Hardware | DERCHI handle & hinges | Custom finishes available |
Size Range | Width 600–850mm; Height 1800–2500mm | Clear opening dimensions per order |
Sealing Material | EPDM rubber strip | |
Application | Indoor partitions, covered exteriors | Exterior use confirmed per project |
Packaging | Optional New 32 Pack | Confirm with order |
Advantages
Custom‑Built to Project Drawings: Each door is fabricated to your specified opening dimensions, eliminating on‑site cutting and speeding up installation.
Reliable Material Quality: 6063‑T5 alloy paired with EPDM seals creates a durable swing door that withstands daily use in commercial settings.
Energy‑Efficient Glazing: The double-glazed option achieves U‑0.39, giving it a measurable edge in interior climate control.
Flexible Handing & Swing: Left- or right-hand, outswing or inswing configurations fit both new builds and renovation plans.
Dedicated B2B Support: Technical documents and test reports are provided on request, and packaging choices like the New 32 Pack are discussed during ordering.
Application Scenarios
Apartment: Bedroom or study door: the outward swing frees up floor space, and double glazing dampens noise from adjacent rooms.
Home Office: Separates work zone without crowding the room; 37 dB sound reduction supports focused calls and meetings.
Hotel: Guest room entrance that opens into the corridor — a layout common in hospitality. The aluminum finish integrates with modern fit-outs.
Office Building: Conference room glass partition that brings daylight into hallways; swing direction can be set to match access patterns.
Outdoor (Covered): For sheltered loggias or covered terraces, 300 Pa water tightness and EPDM seals offer adequate protection; confirm finish suitability for your climate.
Residential Building: Interior passage door between living and hallway; custom sizes eliminate awkward gaps and align with wall finishes.
Exterior (Fully Exposed): When installed in exposed positions, additional weatherproofing and corrosion-resistant finish are necessary. Consult our engineers for a site-specific evaluation.
Villa: Garden-facing door to a covered patio: large glass panes frame outdoor views, while the slim 54mm frame keeps sightlines open.
FAQ
What is a left hand outswing exterior door?
A door with hinges on the left side when viewed from outside, swinging away from the building. This configuration can be ordered on the aluminum profile.
Where can this door be used?
It performs best as an interior partition, study, or space divider, and may be used in covered exterior entries. For fully exposed locations, confirm weather resistance with our technical department.
Can it be customized to right hand or inswing?
Yes. Swing direction and handing are defined at order. Specify right-hand, inswing, or any combination to match your door schedule.
What information is needed for a quote?
Provide opening dimensions, handing, glass choice, finish preference, quantity, project location, and any required performance tests. This allows us to prepare an accurate offer.
Can this door be used for B2B projects?
Absolutely. Adjustable sizing, custom finishes, and export packaging make the suitable for hotel, office, and multi-residential projects. Request a commercial quotation with your details.
Are technical documents available?
Test reports for air tightness, water tightness, and sound insulation are available upon request, along with profile drawings and hardware specifications. Specify the standards you need with your inquiry.
What should buyers confirm before ordering?
Verify exact handing, opening direction, and whether the location demands exterior-grade performance. Have structural opening dimensions ready, and request a pre‑production sample or shop drawing for approval.
How are packaging, shipping, and compliance handled?
Standard or optional New 32 Pack is available. Shipping terms and incoterms are agreed at quotation. Buyers should confirm that required compliance documents apply to the ordered configuration and destination country.
