The 24 x 36 casement window is a made-to-size aluminum crank casement window designed for B2B residential and light commercial projects. It features a 6063-T5 aluminum frame, EPDM sealing, and double tempered glass.
- Hand-crank outward opening for controlled ventilation in hard-to-access placements
- 6063-T5 aluminum frame with EPDM rubber strip sealing for weather resistance
- Customizable glass package, color, and screen options to meet project specifications
Product Details
This 24 x 36 casement window uses a cranked-out sash mechanism operated by a hand crank, offering controlled ventilation without reaching. The 6063-T5 aluminum profile features 1.4 mm wall thickness and EPDM rubber strip sealing. Three frame depth options (72/86/100 mm) accommodate different double tempered glass packages, allowing buyers to match structural needs and budgets.
The 610 x 914 mm nominal size fits compact openings in kitchens, bathrooms, and stairwells. Made-to-size manufacturing solves rough-opening mismatches. Opening direction (left or right crank side) and screen configuration are confirmed per project requirements at quotation.
Product Features
Hand-Crank Operation: Outward crank opening provides controlled ventilation without reaching, suitable for hard-to-access placements like above counters or stairwells.
Aluminum Frame: 6063-T5 aluminum profile with 1.4 mm thickness offers structural stability for residential and light commercial projects, with corrosion resistance for exterior exposure.
EPDM Sealing: Rubber strip sealing reduces air and water infiltration, supporting 350 Pa water resistance and 5 KPa wind resistance for exposed facades.
Double Tempered Glass: Available in 5+27A+5 mm or 5+15A+5 mm configurations, providing safety glazing with 30 dB sound insulation and 0.39 U-Factor for energy-conscious projects.
Frame Depth Options: Three depths (72/86/100 mm) allow buyers to match glass package and thermal performance to project budget and local code requirements.
Made-to-Size Customization: Manufacturing from nominal dimensions supports non-standard openings and project-specific layouts including fixed and operable combinations.
Customizable Styles
Glass Package: Choose between 5+27A+5 mm (WY-72/WY-100) or 5+15A+5 mm (WY-86) double tempered glass; argon fill and warm-edge spacer upgrades available.
Frame Depth: Select 72 mm, 86 mm, or 100 mm frame depth based on desired glass package, structural requirements, and project budget constraints.
Size: Made-to-size from nominal 610 x 914 mm; cranked-out panel range W450-800 mm x H600-1500 mm supports various opening dimensions for project fit.
Color: Choose from Pearl White, Quartz Gray, Starry Sky Black, Deep Sea Blue, wood grain finishes, and more; PVDF fluorocarbon coating available with upcharge.
Layout: Single casement, awning, or fixed and operable composite; additional layouts include double sash, three-segment, and irregular shapes from buyer-supplied images.
Hardware Accessories
Hand Crank: American hand crank for WY-72 or Australian hanging hand crank for WY-86/WY-100; regional hardware variant selected by target market and project location.
Lock Seat: Multi-point switch lock seat (WY-72) or single-point switch lock seat (WY-86/WY-100) provides secure sash locking for residential and commercial security needs.
Casement Limiter: Optional simple limiter (+60 RMB/pc) or safety limiter (+168 RMB/pc) controls opening angle for ventilation management and child-safety compliance.
Screen Mesh: Options include 304 high-definition mesh, king kong mesh, 48-mesh high-transparency mesh, and anti-theft screen; compatibility varies by series, confirm per model.
Sealing and Track: EPDM rubber strip provides continuous weather sealing; outward top-hung hardware set (+1650 RMB/set) available for alternative operation mode on suitable configurations.
Basic Parameters
Performance Item | Available Information | Buyer Notes |
|---|---|---|
Thermal Insulation | U-Factor 0.39, SHGC 0.25 | Confirm which glass configuration applies; argon fill and warm-edge spacer can improve performance. |
Wind Pressure Resistance | 5 KPa | Confirm this meets project-specific wind load requirements per local building code. |
Water Tightness | 350 Pa | Verify if this meets local code for the project wind and rain exposure zone. |
Air Tightness | 4.5 m3/(m·h) | Confirm testing standard used (GB, ASTM, EN) and local compliance requirements. |
Sound Insulation | 30 dB | Confirm if higher sound insulation is needed; sound/thermal cotton upgrade available at +168 RMB/m2. |
Product Specifications
Specification | Details |
|---|---|
Nominal Size | 24 x 36 in (610 x 914 mm) |
Approximate Area | 0.56 m2 |
Frame Material | 6063-T5 aluminum profile |
Profile Thickness | 1.4 mm (local catalog) |
Frame Depth Options | 72 mm / 86 mm / 100 mm |
Glass (WY-72/WY-100) | Double tempered 5+27A+5 mm |
Glass (WY-86) | Double tempered 5+15A+5 mm |
Sealing | EPDM rubber strip |
Opening Method | Flat opening / hanging up, hand-crank operation |
Opening Panel Range | W450-800 mm x H600-1500 mm |
Water Resistance | 350 Pa |
Air Leakage | 4.5 m3/(m·h) |
Wind Resistance | 5 KPa |
Sound Insulation | 30 dB |
U-Factor | 0.39 |
SHGC | 0.25 |
Notes | Final specifications confirmed per selected series (WY-72/WY-86/WY-100) and project requirements at quotation stage. |
Advantages
Made-to-Size Manufacturing: Custom dimensions from nominal 610 x 914 mm support project-specific openings without costly retrofitting or gap-filling on site.
Flexible Frame Depths: Three frame depth options with corresponding glass packages allow buyers to balance thermal performance, structural needs, and project budget.
Regional Hardware Variants: American and Australian crank options serve different market standards and buyer preferences for global project sourcing.
Export-Grade Packaging: Wooden frame, PE film, air bags, and pallet fixing protect windows during sea freight for international B2B orders.
Transparent Upgrade Pricing: Itemized pricing for glass, hardware, screens, and coatings gives procurement teams clear cost control for project budgeting.
Application Scenarios
Apartment: Fits compact apartment openings in kitchens and bathrooms; hand-crank operation enables ventilation control in tight spaces without obstructing interior walkways.
Home Office: Crank-out operation provides adjustable airflow for home office environments; double tempered glass with 30 dB sound insulation helps reduce external noise distractions during work hours.
Hotel: Standardized nominal size supports hotel room window schedules; EPDM sealing and multi-point or single-point lock hardware meet hospitality security and weather performance requirements.
Office Building: Aluminum frame with 5 KPa wind resistance suits commercial facades; frame depth options allow specifiers to match thermal and structural requirements for office building projects.
Outdoor: Outward cranked-out sash is suitable for outdoor-facing enclosures and balconies; 350 Pa water resistance handles rain exposure while crank mechanism allows operation from inside.
Residential Building: Made-to-size customization from 610 x 914 mm nominal supports varied residential window schedules; color families and wood grain finishes match interior and exterior design schemes.
Exterior: 6063-T5 aluminum profile with corrosion resistance suits exterior facade applications; PVDF fluorocarbon coating option provides additional weathering protection for long-term exterior performance.
Villa: Multiple color options including Starry Sky Black, Deep Sea Blue, and Black Walnut wood grain support villa design aesthetics; safety limiter and screen mesh options enhance residential security and comfort.
Inquiry Guidance
To request a quote, please share your project location, required size, quantity, preferred frame color, glass type, hardware requirements, and drawings or reference photos if available.
FAQ
How do I get a quote for the 24 x 36 casement window?
Provide nominal size, desired series (WY-72/86/100), frame depth, glass package, color, opening direction, screen type, and project quantity. DERCHI confirms price after reviewing drawings and specifications.
Can I customize the frame depth, glass, and color?
Yes. Choose from 72/86/100 mm frame depths, two double tempered glass configurations, 12+ color families with PVDF upcharge, and various screen and hardware options. Final selections confirmed at quotation.
How do I confirm this window meets my project wind load and code requirements?
Share your project country, local building code, and wind load requirements. DERCHI reviews performance parameters (5 KPa wind, 350 Pa water) against your specs and advises on suitability or upgrades.
Are CAD drawings and test reports available?
General dimensional references are available. Final CAD drawings and applicable test reports are provided after series selection and order confirmation. Confirm specific certification applicability before publishing claims.
What information must I provide before ordering?
Provide rough opening dimensions, opening direction (left/right crank), series selection, glass package, color (interior/exterior), screen type, safety components, project quantity, and destination country for compliance review.
How are windows packaged for export?
Wooden-frame packaging with protective tape, pallet fixing, plastic belts, PE films against seawater, and air bags between pallets. Suitable for sea freight. Confirm packaging details and Incoterms at quotation.
What is the minimum order quantity and lead time?
Customization is available from small quantities. Lead time is indicative only and confirmed per order based on quantity, series, and customization scope. Contact DERCHI for current MOQ and delivery schedule.
