The 24x48 casement window is a made-to-size crank-out aluminum window with a nominal size of 24 x 48 in (610 x 1219 mm). Built with 6063-T5 aluminum profiles and double tempered glass, it suits project procurement, contractor supply, and importer sourcing.
- Three frame depth options: 72, 86, or 100 mm to match performance requirements
- Hand-crank flat opening operation for controlled ventilation
- EPDM rubber strip sealing with configurable glass, screen, and color options
Product Details
The 24x48 casement window uses a 6063-T5 aluminum profile with 1.4 mm wall thickness and EPDM rubber strip sealing. Three frame depth options — WY-72, WY-86, and WY-100 — determine both glass package and hardware type: the 72 mm and 100 mm frames pair with 5+27A+5 mm double tempered glass and an American hand crank, while the 86 mm frame uses 5+15A+5 mm glass with an Australian hanging crank. This crank out casement window opens via flat-opening or top-hung hand-crank operation.
For buyers evaluating a custom casement window, the made-to-size approach addresses project-specific opening dimensions within the suggested panel range of W450–800 x H600–1500 mm. Unlike off-the-shelf alternatives, this 24 x 48 aluminum window allows configurable glass upgrades, screen selection, color finishes, and safety hardware — giving specifiers flexibility across building types and performance tiers.
Product Features
Hand-Crank Operation: The crank mechanism allows controlled ventilation and secure partial opening, making this aluminum casement window practical for hard-to-reach placements above counters or furniture.
6063-T5 Aluminum Frame: With 1.4 mm profile thickness, the frame provides structural stability for daily operation while keeping overall window weight manageable for standard wall openings.
Double Tempered Glass: This double tempered glass window uses 5+27A+5 mm or 5+15A+5 mm configurations by series, offering impact resistance and safety compliance for residential and commercial projects.
EPDM Rubber Sealing: Continuous EPDM sealing along the frame perimeter helps manage air infiltration and water penetration, supporting rated performance values under standard testing conditions.
Three Frame Depth Options: Buyers can select 72, 86, or 100 mm frame depths to match project thermal and structural requirements without committing to a single fixed specification.
Made-to-Size Production: Manufacturing follows project-specific dimensions within the proven opening panel range, reducing on-site fitting issues and supporting consistent installation across multi-unit developments.
Customizable Styles
Layout Configuration: Choose single casement, awning, or fixed-plus-operable composite styles; multi-sash, three-segment, and bay window combinations are also available per project drawings.
Glass Package: Standard double tempered glass with optional upgrades including argon fill, warm-edge spacer, Low-E, laminated, triple glazing, and blind-glass units.
Frame Depth: Select 72, 86, or 100 mm frame depth based on structural, thermal, and glass thickness requirements for the target project environment.
Color and Finish: Twelve standard color families including Pearl White, Quartz Gray, and Black Walnut wood grain; PVDF fluorocarbon and custom coatings available with upcharge.
Size Customization: Made-to-size production within the suggested opening panel range of W450–800 x H600–1500 mm; final dimensions confirmed per project window schedule.
Hardware Accessories
American Hand Crank (WY-72): Paired with a multi-point switch lock seat, this crank assembly suits the 72 mm frame depth configuration for standard residential applications.
Australian Hanging Hand Crank (WY-86/WY-100): Used with a single-point switch lock seat on 86 mm and 100 mm frames; confirm compatibility with project hardware preferences.
Casement Limiters: Optional simple limiter or safety limiter add-ons control opening angle; select based on ventilation control and child-safety requirements per project.
Screen Options: Anti-theft screen, 304 stainless HD mesh, King Kong mesh, and 48-mesh high-transmission mesh available; compatibility varies by series and must be confirmed.
Safety Fence: Fixed or opening safety fence available as an optional add-on; confirm selection and series compatibility during the quotation stage.
Basic Parameters
Performance Item | Available Information | Buyer Notes |
|---|---|---|
Thermal Insulation | U-Factor 0.39; SHGC 0.25 | Confirm units (SI or IP) and applicable glass configuration; argon and warm-edge upgrades available. |
Wind Pressure Resistance | 5 KPa | Confirm this rating meets local wind load code requirements for the project site. |
Water Tightness | 350 Pa | Verify whether this value satisfies local building code water penetration requirements. |
Air Tightness | 4.5 m³/(m·h) | Confirm the testing standard used, as methods vary between Chinese GB and international standards. |
Sound Insulation | 30 dB | Confirm if acoustic performance meets project requirements; laminated or triple glass upgrades available. |
Product Specifications
Specification | Detail |
|---|---|
Product Name | 24x48 Casement Window |
Type | Cranked-out casement (flat opening / top-hung) |
Nominal Size | 24 x 48 in (610 x 1219 mm), ~0.74 m² |
Material | 6063-T5 aluminum, 1.4 mm profile, EPDM strip |
Frame Depth | 72 mm (WY-72) / 86 mm (WY-86) / 100 mm (WY-100) |
Glass | WY-72/WY-100: 5+27A+5 mm; WY-86: 5+15A+5 mm double tempered |
Opening Range | W450–800 x H600–1500 mm, hand-crank operation |
Hardware | American crank + multi-point lock (WY-72); Australian crank + single-point lock (WY-86/100) |
Color Options | 12+ standard families; PVDF/wood grain with upcharge |
Supply / Delivery | 20,000 m²/month; 25–35 days general range, confirm per order |
Customization | Made-to-size; glass, screen, color, hardware configurable |
Notes | Final series, glass, color, and hardware confirmed at quotation stage |
Advantages
Made-to-Size Production: Manufacturing follows project-specific dimensions within the proven opening panel range, reducing fitting issues on site.
Three Frame Depth Tiers: The 72, 86, and 100 mm options let buyers match performance requirements without over-specifying or under-delivering.
Crank Operation Flexibility: Hand-crank opening enables controlled ventilation in installations where direct reach or exterior swing access is limited.
Configurable System: Glass, screen, color, safety hardware, and finish options support diverse project specifications across residential and commercial applications.
Export-Ready Packaging: Wooden-frame packaging with pallet fixing, PE films, plastic belts, and air bags supports international container shipping.
Application Scenarios
Apartment: The 24x48 size and crank operation suit compact urban kitchens and bathrooms where exterior swing clearance is tight and controlled ventilation is needed.
Home Office: Hand-crank opening allows airflow adjustment from a seated desk position without reaching over work surfaces, supporting comfort during extended work sessions.
Hotel: Guest rooms benefit from 30 dB sound insulation and controlled opening; specifiers can select color finishes to coordinate with interior design schemes.
Office Building: Configurable glass packages and frame depths let specifiers address thermal and acoustic requirements across different floor levels and building orientations.
Outdoor: For outdoor-facing enclosures, buyers should confirm water tightness, wind pressure ratings, and surface finish durability against local climate exposure conditions.
Residential Building: Multi-unit developments can standardize on one frame depth and color while varying glass packages by elevation to manage cost and performance.
Exterior: Exterior facade applications require confirmation of wind load compliance, sealing performance, and installation detailing specific to the wall system used.
Villa: Customizable color families and glass upgrades allow villa projects to coordinate window appearance with architectural materials while meeting room-specific performance needs.
Inquiry Guidance
To request a quote, please share your project location, required size, quantity, preferred frame color, glass type, hardware requirements, and drawings or reference photos if available.
FAQ
What is the 24x48 casement window?
It is a made-to-size crank-out aluminum window with a nominal size of 24 x 48 in (610 x 1219 mm). It uses 6063-T5 aluminum profiles, double tempered glass, and EPDM sealing, available in three frame depth options.
Where can this window be used?
It suits apartments, hotels, villas, office buildings, residential developments, and home offices. Specific room applications include kitchens, bathrooms, bedrooms, living rooms, stairwells, and balconies depending on opening mode and configuration.
Can the window be customized?
Yes. Buyers can configure layout style, glass package, frame depth, color finish, screen type, and safety hardware. Final layout depends on operation side and screen selection, confirmed during quotation.
What information is needed to get a quote for a 24x48 casement window?
Provide project drawings or window schedule, opening direction (left or right crank), desired frame depth, glass package, color selection, screen type, safety components, and total quantity. These details ensure accurate pricing.
How do I choose between WY-72, WY-86, and WY-100 frame depths?
Selection depends on required glass thickness, thermal performance, and hardware preference. WY-72 and WY-100 use 5+27A+5 mm glass with American crank; WY-86 uses 5+15A+5 mm with Australian crank. Confirm during quotation.
What is the lead time and how is the window packaged?
General delivery ranges 25–35 days per E6N commercial terms; actual lead time is confirmed per order. Export packaging includes wooden frames, protective tape, pallets, plastic belts, PE films, and air bags.
What should buyers confirm before ordering?
Confirm rough opening dimensions, local wind load code compliance, certification applicability for the target market, final glass and hardware selection, color, and warranty terms with the supplier before production.
