A 24 x 60 casement window provides a tailored outward opening solution for commercial and residential builds. Built with thermal break aluminum, it supports energy efficiency and project-specific customization.
- Nominal size of 24 x 60 in (610 x 1524 mm), covering approximately 0.93 m2.
- Constructed from 6063-T5 aluminum with a 109/118/127 mm frame-depth family.
- Standard 5+27A+5 mm double tempered insulated glass with argon gas fill.
- Configurable sash layouts, hardware, and color finishes to meet project requirements.
Product Details
The structural foundation of this 610 x 1524 mm window relies on thermal break 6063-T5 aluminum profiles, available in a 109/118/127 mm frame-depth family. The system integrates a PA66 insulation strip and argon-filled double tempered glass, working together to manage thermal transfer and support energy-efficient building envelopes.
As an outward opening casement window, it saves interior space while directing airflow effectively. It differs from standard units by offering target high-performance specs and multiple sash combinations, such as fixed transoms or lower panels. Buyers should confirm specific sealing, drainage structures, and final series selection to align with their project's structural and code requirements.
Product Features
Thermal Break Aluminum: The 6063-T5 frame with PA66 insulation strips reduces thermal transfer, helping projects meet energy efficiency targets.
Outward Opening Mechanism: Push-out or awning operation saves interior space and captures side breezes, improving room ventilation without obstructing indoor layouts.
Insulated Glass Unit: Standard 5+27A+5 mm double tempered glass with argon gas helps control temperature and sound transmission for occupant comfort.
Flexible Sash Layouts: Configurations include single sash, double sash, or side-opening with center fixed panels to match various facade alignment needs.
WEHAG Hardware System: Equipped with WEHAG handles and hinges, the window offers smooth operation and secure closure for daily use.
Project Color Options: Finishes like Pearl White, Quartz Gray, and wood grain allow architects to match window aesthetics to building design requirements.
Customizable Styles
Glass Configuration: Upgrades include Low-E, laminated, triple, tinted, and reflective glass to meet specific project performance needs.
Frame Color and Finish: Options span Pearl White, Quartz Gray, and wood grain; PVDF custom colors may require additional upcharges.
Size Customization: While nominal size is 24 x 60 in, dimensions can be adjusted from a 2 m2 minimum to fit project drawings.
Sash Layout Options: Choose from single sash, double sash, or side-opening with center fixed combinations per facade requirements.
Screen and Opening: Select left or right opening directions and add anti-theft, 304 mesh, or diamond mesh screens for protection.
Hardware Accessories
WEHAG Handle: Available in black or silver, providing ergonomic grip and durable operation for daily outward opening use.
WEHAG Hinge: Supports secure sash attachment and smooth outward swing, designed to handle the window's structural load.
Multi-Point Lock: Features a two-point or six-point locking system depending on the selected series, enhancing security and sealing.
Casement Limiters: Optional simple or safety limiters control the opening angle, preventing wind damage and ensuring controlled ventilation.
Safety Fences and Screens: Optional fixed or opening safety fences and mesh screens provide added protection and insect control.
Basic Parameters
Performance Item | Available Information | Buyer Notes |
|---|---|---|
Thermal Insulation | U-Factor 0.23 (target) | Target spec; must be confirmed for the selected series and final glass configuration. |
Wind Pressure Resistance | 5 KPa (target) | Must be verified against the project country's local wind-pressure code requirements. |
Water Tightness | 700 Pa (target) | Target value; buyers should confirm drainage structure and sealing for the chosen series. |
Air Tightness | 1.2 m3/(m.h) (target) | Confirm this target spec is achievable with the final hardware and sash layout selection. |
Sound Insulation | 35 dB (target) | Target rating; actual performance depends on the final glass package selection. |
Product Specifications
Specification | Details |
|---|---|
Product Name | 24 x 60 Casement Window |
Product Type | Outward opening / awning casement window |
Material | Thermal-break 6063-T5 aluminum |
Nominal Size | 24 x 60 in (610 x 1524 mm) |
Approximate Area | 0.93 m2 |
Frame Depth | 109/118/127 mm family |
Profile Thickness | 1.8-2.0 mm depending on series |
Glass Type | Double tempered insulated glass |
Glass Thickness | 5+27A+5 mm with argon gas |
Hardware | WEHAG handle, hinge, multi-point lock |
Opening Style | Outward opening / awning |
Customization | Size, color, glass, and sash layout available from 2 m2 |
Notes | Final specifications require procurement confirmation based on selected series. |
Advantages
Energy-Efficient System: The thermal break aluminum frame with PA66 strips supports modern building envelope requirements and energy performance targets.
Structural Integrity: Built with 6063-T5 aluminum and 1.8-2.0 mm profile thickness, providing a sturdy foundation for outward opening sashes.
Flexible Customization: Options for glass upgrades, sash layouts, and finishes allow tailored solutions for diverse architectural project needs.
Reliable Hardware: Integration of WEHAG handles, hinges, and multi-point locks supports secure and smooth long-term daily operation.
Project-Ready Support: DERCHI casement window offerings include custom project support and export-ready packaging for global B2B buyers.
Application Scenarios
Apartment: The outward opening mechanism saves valuable interior floor space, making it suitable for compact urban units where maximizing usable area is a priority.
Home Office: Argon-filled insulated glass helps maintain a stable indoor temperature and reduce outdoor noise, supporting a focused work environment.
Hotel: Available in finishes like Pearl White and Deep Coffee, the window can be tailored to match interior design themes while providing secure ventilation.
Office Building: The 109/118/127 mm frame-depth family accommodates commercial facade alignment, offering consistent sightlines across multi-story installations.
Outdoor: For outdoor-facing enclosures, buyers must confirm water tightness, wind pressure resistance, and surface finish durability against local weather conditions.
Residential Building: The thermal break aluminum construction aids in meeting residential energy codes, providing comfortable living spaces across various climates.
Exterior: When used on exterior facades, confirm the specific series and glass package meet local structural requirements and project-specific performance targets.
Villa: Customizable sash layouts, including side-opening with center fixed panels, allow architects to create symmetrical and visually appealing villa elevations.
Inquiry Guidance
To request a quote, please share your project location, required size, quantity, preferred frame color, glass type, hardware requirements, and drawings or reference photos if available.
FAQ
What is a 24 x 60 casement window?
It is an outward opening window with a nominal size of 24 x 60 inches (610 x 1524 mm), built with thermal break 6063-T5 aluminum and double tempered insulated glass for project applications.
Where can this window be used?
It is suitable for apartments, hotels, office buildings, residential homes, and villas. Buyers should verify performance specs and sealing structures for outdoor or exterior facade applications.
Can the window be customized for projects?
Yes, size, color, glass type, and sash layout are customizable. Options include Low-E glass, various wood grain finishes, and single or multi-sash configurations starting from a 2 m2 minimum.
What information is needed to get a quote for a 24 x 60 casement window?
Buyers should provide project drawings, desired series, opening direction, glass package, color finish, and local wind-pressure code requirements to receive an accurate and current quote.
What is the lead time and minimum order quantity?
Indicative lead time is 25-35 days, and reference MOQ is 2 m2. Both metrics depend on final order volume and configuration, so buyers should confirm details per order.
Are technical documents and certifications available?
DERCHI official pages cite global certifications like NFRC, CE, and AS2047. Buyers must confirm whether specific test reports apply to their selected series and target market.
What should buyers confirm before ordering?
Confirm the final model selection, opening side, hardware brand, screen type, and warranty terms. Also verify packaging details and shipping arrangements to ensure smooth project delivery.
