DERCHI supplies aluminum sliding doors built for Venezuela’s hot, humid climate. The range spans light residential to heavy commercial systems, all customizable with OEM/ODM options and factory-direct bulk pricing.
- Tropical‑climate engineering: hidden drainage, EPDM seals, PVDF coatings
- Four series – Q5, Q9, 135D, Q15 – from apartment balconies to luxury villa entrances
- Custom dimensions, glass, colors, and hardware – including private‑label branding
Product Details
DERCHI sliding doors are built with 6063‑T5 thermal break aluminum. Multi‑track configurations hold double‑glazed insulating glass — 5mm+27A+5mm or 8mm+21A+8mm — to form a reliable thermal envelope. Hidden nine‑step drainage and EPDM composite seals manage heavy rainfall and coastal spray. Siliconized wool pile and quiet pulley mechanisms keep operation smooth and low‑noise.
The Q5 (2‑track/3‑track) covers apartments and light commercial spaces; the slim‑frame Q9 (20mm visible width) suits high‑end residences and hotels; the 135D with PVDF finish and argon‑filled glass serves mid‑rise commercial projects; and the heavy Q15 handles openings up to 4000mm wide and 6000mm high, with motorization up to 1000kg per leaf. All models accept Low‑E coatings, argon gas fill, and corrosion‑resistant hardware for coastal projects.
Product Features
Thermal insulation: U‑Factors from 0.28 (Q15) to 0.38 (135D) reduce solar heat gain and cooling loads.
Wind pressure resistance: Tested to 4.5 kPa for 135D and Q15, meeting many coastal wind load requirements.
Water tightness: Ratings from 350 Pa to 450 Pa, plus hidden drainage and backflow control, protect interiors during heavy rain.
Quiet operation: Double‑row silent pulleys and anti‑swing wheels minimize noise — important in hotels and offices.
Corrosion resistance: PVDF‑coated frames and 304 stainless steel hardware withstand salt spray and humidity.
Air sealing: Multi‑layer EPDM seals and siliconized wool pile achieve air tightness of 3.0 m³/(m·h), keeping dust and unconditioned air out.
Customizable Styles
Glass options: Insulated double‑glazed units with Low‑E, tinted, or tempered glass; argon gas fill available for better thermal performance.
Frame finishes: PVDF fluorocarbon, powder coating, anodized, and wood‑grain finishes in standard RAL colors; custom colors subject to confirmation.
Track layouts: 2‑track, 3‑track, single‑track, or barrier‑free configurations; exact dimensions confirmed during order.
Sash dimensions: Widths from 580mm to 4000mm and heights up to 6000mm depending on series; oversized panels may need structural review.
Optional add‑ons: Built‑in magnetic/electric blinds, folding screens, motorized operation, key locks, and buffer systems available per project.
Hardware Accessories
Quiet roller system: Four‑wheel carriages with top anti‑swing/anti‑derail wheel (Q5) provide stable, low‑noise sliding.
Handles & locks: HOPO/HOPPE handles with 304 stainless steel hook or side interlock locks deliver security and a refined finish.
Motorized drive: HY‑120 to HY‑1000 operators support up to 1000 kg per leaf; limit switches and remote control integrate with smart building systems.
Weather seals: EPDM composite gaskets and siliconized wool pile form a durable barrier against wind‑driven rain.
Accessories: Buffer, floor guide, and magnetic catch hardware can be specified; OEM branding on handles and locks supported.
Basic Parameters
Performance Item | Available Information | Buyer Notes |
|---|---|---|
Thermal Insulation | U‑Factor 0.28 (Q15) – 0.38 (135D); other series upon request | Request the test report for your specific glass configuration and climate zone. |
Wind Pressure Resistance | Up to 4.5 kPa (135D, Q15); lower for lighter series | Verify local design wind loads and confirm the required rating with your structural engineer. |
Water Tightness | 350 Pa (135D) to 450 Pa (Q15); Q5/Q9 may vary | For coastal areas with heavy rain, discuss whether a higher rating is needed. |
Air Tightness | 3.0 m³/(m·h) tested on 135D; other series data available on request | Confirm the air leakage class suits your building envelope specification. |
Sound Insulation | 32 dB (135D) – 35 dB (Q15); acoustic laminate may increase values | If noise reduction is critical, request acoustic glass options and laboratory test data. |
Product Specifications
Parameter | Q5 | Q9 | 135D | Q15 |
|---|---|---|---|---|
Track Options | 2-track / 3-track | Single-track / Double-track | 2-track / 3-track | 2-track / 3-track |
Frame Thickness | 2.2mm main, 1.8mm sash | 2.2mm, load-bearing 6.0mm | 1.8mm main, 1.6mm sash | 2.2mm thermal break |
Standard Glass | 5mm + 27A + 5mm | 8mm + 21A + 8mm | 5mm + 27A + 5mm (optional 5+20+5) | 8mm + 21A + 8mm |
Max Sash Size | W 1500mm, H 3000mm | W 3000mm, H 4000mm | Upon request | W 4000mm, H 6000mm |
Key Features | Four-wheel silent, hidden drainage | 20mm visible width, smart control | PVDF finish, argon gas, HOPO hardware | Motor up to 1000kg, EPDM seals, high wind/water ratings |
Typical Use | Apartment, balcony, light commercial | High-end residential, villa, hotel | General commercial, mid-rise residential | Heavy commercial, luxury villa, patio entrances |
Advantages
Factory‑direct supply: DERCHI’s Foshan factory (ISO9001‑certified, 70,000 sqm) supplies bulk orders with typical 25‑day lead times for standard configurations.
OEM/ODM expertise: Custom profiles, private‑label hardware branding, and tailored finishes let you differentiate your local product line.
Tropical climate engineering: Corrosion‑resistant 304 stainless hardware, PVDF coatings, and multi‑step drainage address Venezuela’s coastal and humid zones.
Multi‑series range: One supplier covers light residential, slim‑frame luxury, and heavy‑duty commercial needs — reducing procurement complexity.
Project documentation: Shop drawings, CAD/BIM details, installation guides, and available test reports support specification by architects and contractors.
Application Scenarios
Apartment: Q5 sliding doors provide balcony access with 2‑track operation; built‑in drainage keeps units dry during afternoon downpours.
Home Office: Q9’s slim 20mm profile maximizes daylight, while acoustic insulation supports focused calls.
Hotel: 135D or Q15 heavy sliding entrances offer wide, silent gliding panels; motorized options suit barrier‑free lobby design.
Office Building: Q5 or Q9 serve as interior partitions, offering privacy without blocking daylight, and can meet fire‑exit clearance when configured correctly.
Outdoor: Q15 sliding doors with 450 Pa water tightness and motorized operation turn patios into weather‑protected spaces; verify wind exposure and installation slope for long‑term performance.
Residential Building: Q5 cost‑effective thermal break and multi‑point locking fit main entrances; custom sizes accommodate renovation openings.
Exterior: 135D PVDF‑coated doors with 4.5 kPa wind resistance suit exposed façades; confirm wind load maps and drainage path during shop drawing stage.
Villa: Q9 or Q15 grand sliding panels connect interiors to gardens or pools; motorization and integrated screens can be discussed for mosquito control.
FAQ
What is an aluminum sliding door Venezuela solution from DERCHI?
DERCHI supplies thermal‑break aluminum sliding doors in multiple series, built for tropical climates and shipped factory‑direct to Venezuelan importers with full customization.
Where can these sliding doors be used in Venezuela?
They work for apartments, villas, hotels, office buildings, and commercial projects in coastal, urban, and inland regions where corrosion resistance and thermal performance matter.
Can I customise glass, colours, and sizes?
Yes, custom sliding doors are a core strength. You choose Low‑E, tinted, or tempered glass, RAL/PVDF finishes, and dimensions to match your architectural plans.
What information is needed for a quote?
Provide opening dimensions, quantity, target series, glass type, hardware preference, and project location. Our team will prepare a factory‑direct price with shipping and packaging details.
Do you support B2B bulk orders and container shipping?
Absolutely. DERCHI offers FCL shipping from Guangzhou, sample evaluation, and competitive volume pricing for distributors and contractors.
What technical documents are provided?
Shop drawings, CAD and BIM files, installation manuals, and test reports (CE, NFRC, AS2047 where applicable) are supplied to support your project’s approval and construction phases.
What should buyers confirm before ordering?
Verify local building code requirements, wind loads, opening dimensions, and electrical specs for motorized options. Confirm packaging terms and any additional certification needs.
How do I confirm certifications, packaging, and compliance?
Request the specific test certificates for your chosen series and configuration. Packaging is typically wooden crates; details, labelling, and compliance documents can be coordinated with your sales contact.
