A 24x24 casement window delivers controlled ventilation and weather protection in compact residential and commercial openings. Part of the DERCHI WY cranked-out window family, it pairs a hand-crank mechanism with 6063-T5 aluminum construction for projects requiring reliable airflow management in tight spaces.
- 6063-T5 aluminum frame with EPDM rubber strip sealing
- WY-72, WY-86, and WY-100 frame depth options (72/86/100 mm)
- Hand-crank operation with multi-point or single-point switch lock seat
- Made-to-size production for project-specific rough openings
Product Details
The 24x24 casement window uses a 6063-T5 aluminum profile (1.4 mm thickness) sealed with EPDM rubber strips. Double tempered glass configurations vary by series: WY-72 and WY-100 use 5+27A+5 mm, while WY-86 uses 5+15A+5 mm. The hand-crank cranked-out mechanism differs from traditional push-out designs by allowing precise airflow control in hard-to-reach areas. Frame depth options of 72, 86, and 100 mm address different structural and thermal requirements across markets.
With a compact 610x610 mm nominal size, this aluminum casement window 24x24 suits kitchens, bathrooms, stairwells, and compact urban units. The cranked-out design solves ventilation challenges in tight spaces while maintaining 350 Pa water resistance and 5 KPa wind load performance. Made-to-size production and extensive customization options support project-specific adaptation for B2B procurement.
Product Features
Hand-Crank Operation: Enables precise airflow control and easy operation in hard-to-reach placements, offering a practical alternative to traditional push-out mechanisms.
6063-T5 Aluminum Frame: Provides structural strength and corrosion resistance for exterior applications, supporting long-term performance in exposed conditions.
EPDM Rubber Sealing: Reduces air infiltration and improves weather tightness, contributing to energy efficiency and occupant comfort.
Double Tempered Glass: Delivers safety, thermal performance, and 30 dB sound reduction for residential and commercial comfort.
Multiple Frame Depths: 72, 86, and 100 mm options allow adaptation to different climate zones and local building code requirements.
Made-to-Size Production: Project-specific dimensions within the opening panel range ensure efficient B2B procurement without material waste.
Customizable Styles
Glass: Standard double tempered; upgrades include triple, laminated, Low-E, and blind-glass; confirm selection and pricing at quotation.
Frame Depth: Choose 72 mm, 86 mm, or 100 mm profile depth to match thermal and structural requirements of your target market.
Size: Made-to-size production within opening panel range W450-800 mm x H600-1500 mm for project-specific rough openings.
Color: Pearl White, Quartz Gray, Starry Sky Black, Deep Sea Blue, wood grain finishes; PVDF and custom colors available with upcharge.
Style: Single casement, awning, fixed+operable composite, dual sash, side opening+center fixed, irregular/stepped, hexagonal/bay-style combinations available.
Hardware Accessories
Crank Handle: American hand crank (WY-72) or Australian hanging hand crank (WY-86/100) for controlled outward opening operation.
Lock Seat: Multi-point switch lock seat (WY-72) or single-point switch lock seat (WY-86/100) for secure window closure.
Limiter: Simple limiter (+60 RMB/pc) or safety limiter (+168 RMB/pc) for controlled opening angle and safety.
Safety Fence: Fixed/opening safety fence option (+660 RMB/pc) for enhanced security in ground-floor or accessible installations.
Sealing/Thermal: EPDM rubber strip standard; warm-edge spacer (+198 RMB/m2) and argon fill (+36 RMB/m2) available as thermal upgrades.
Basic Parameters
Performance Item | Available Information | Buyer Notes |
|---|---|---|
Thermal Insulation | U-Factor: 0.39 | Confirm which glass configuration this applies to and whether upgrades change this value. |
Wind Pressure Resistance | 5 KPa | Verify against project-specific wind load requirements and local building code. |
Water Tightness | 350 Pa | Confirm which series this applies to and whether it meets local code. |
Air Tightness | 4.5 m3/(m·h) | Confirm applicable series and local standard compliance before ordering. |
Sound Insulation | 30 dB | Confirm if glass upgrade options improve this value for noise-sensitive locations. |
Product Specifications
Specification | Details |
|---|---|
Nominal Size | 24 x 24 in (610 x 610 mm) |
Approximate Area | 0.37 m2 |
Frame Material | 6063-T5 aluminum profile |
Profile Thickness | 1.4 mm |
Frame Depth Options | 72 mm / 86 mm / 100 mm |
Glass (WY-72/WY-100) | Double tempered 5+27A+5 mm |
Glass (WY-86) | Double tempered 5+15A+5 mm |
Sealing | EPDM rubber strip |
Opening Method | Flat opening / hanging up, hand-crank |
Opening Panel Size Range | W450-800 mm x H600-1500 mm |
SHGC | 0.25 |
Delivery | 25-35 days (official E6N terms, confirm per order) |
Supply Ability | 20,000 m2/month |
Advantages
Compact Size: 610x610mm nominal dimensions fit standard small openings in kitchens, bathrooms, and compact urban units.
Frame Depth Options: WY-72/86/100 series allow adaptation to different climate zones and project performance requirements.
Hand-Crank Mechanism: Enables precise airflow control, suited for hard-to-reach window placements and tight interior spaces.
Export Packaging: Wooden frame, PE film, air bags, and pallet fixing support safe international sea freight shipping.
Customization: Extensive glass, color, screen, and hardware options support project-specific requirements without compromising core performance.
Application Scenarios
Apartment: Compact 610x610mm size suits apartment kitchens and bathrooms where space is limited, providing controlled ventilation through hand-crank operation without obstructing walkways.
Home Office: Hand-crank operation allows precise airflow control in home office spaces, maintaining comfort during work hours while 30dB sound insulation reduces external noise distraction.
Hotel: Standardized size supports efficient procurement for hotel room renovations; multiple color and finish options align with interior design themes across different property tiers.
Office Building: 6063-T5 aluminum frame with 5KPa wind load resistance suits commercial facades; hand-crank operation provides maintenance-friendly ventilation for perimeter office zones.
Outdoor: EPDM sealing and 350Pa water resistance support outdoor-facing enclosures; confirm weather resistance, water tightness, and installation conditions for accessible exterior installations.
Residential Building: Made-to-size production accommodates residential window schedules; multiple frame depth options address varying thermal requirements across climate zones for multi-unit developments.
Exterior: Powder coating and PVDF finish options provide exterior weather resistance; confirm surface finish and wind pressure performance for long-term facade applications in exposed conditions.
Villa: Color options including wood grain finishes and Deep Sea Blue complement villa architecture; custom casement window style combinations support distinctive facade designs for high-end projects.
Inquiry Guidance
To request a quote, please share your project location, required size, quantity, preferred frame color, glass type, hardware requirements, and drawings or reference photos if available.
FAQ
How do I get a quote for the 24x24 casement window?
Provide project drawings, required series (WY-72/86/100), glass config, color, screen type, and quantity. DERCHI issues a formal quotation after confirming specifications.
What is the minimum order quantity?
Reference MOQ starts from 2m2 for color and size customization. Confirm final MOQ during quotation as it may vary by customization complexity.
Which frame depth should I choose?
Selection depends on target market climate zone, local building code wind load requirements, and thermal performance targets. Consult DERCHI technical team for guidance.
Can I customize the glass configuration?
Standard is double tempered; upgrades include triple, laminated, Low-E, argon fill, warm-edge spacer, and blind-glass. Confirm pricing and availability at quotation.
What certifications are available?
DERCHI holds NFRC, CE, AS2047, CSA, ISO9001 at brand level. Confirm applicability to this specific product and target market during quotation.
How is the window packaged for export?
Export packaging includes wooden frame, protective tape, pallet fixing, plastic belts, PE films against sea water, and air bags between pallets.
What is the lead time?
Official E6N terms state 25-35 days. Confirm exact lead time per order based on quantity, customization level, and production schedule.
