The 24x72 casement window is a custom-engineered aluminum outward-opening window built for tall residential and commercial openings. It features a thermal-break 6063-T5 aluminum frame and an engineered fixed/operable split-panel option to ensure structural safety for large sash sizes.
- Nominal size 24 x 72 in (610 x 1829 mm), tailored to project rough openings
- Thermal-break 6063-T5 aluminum frame with PA66 insulation strip
- 5+27A+5 mm double tempered insulated glass with argon gas fill
- Extensive glass, color, and hardware customization for project-specific fit
Product Details
This aluminum casement window relies on a thermal-break 6063-T5 aluminum frame within the 109/118/127 mm family, featuring a 2.0 mm profile thickness and a PA66 insulation strip. The standard 5+27A+5 mm double tempered insulated glass includes argon gas and a PVDF aluminum spacer. Because the 24x72 inch dimension exceeds ordinary single-sash ranges, a split layout—such as a fixed transom or lower fixed section paired with an operable sash—is recommended unless hinge and load engineering confirms single-sash viability.
As an outward opening casement window, it delivers cross-ventilation without intruding on interior floor space, making it practical for tight urban rooms and commercial facades. WEHAG engineered hardware manages large sash loads, while glass upgrades including Low-E, laminated, and triple glazing allow buyers to meet specific thermal and acoustic targets. Final configuration, series selection, and structural layout are confirmed per project to ensure code compliance and safety.
Product Features
Thermal-Break Aluminum Frame: The 6063-T5 frame with a PA66 insulation strip reduces heat transfer, supporting energy-efficient performance for large custom casement window openings.
Insulated Argon Glass: This insulated glass casement window uses 5+27A+5 mm double tempered units with argon fill to support target sound and thermal ratings.
Engineered Split-Panel Option: For tall 24x72 openings, a fixed and operable split-panel layout ensures structural safety and helps meet local building code requirements.
WEHAG Hardware System: WEHAG handles and hinges, paired with a multi-point lock, provide secure locking and smooth sash operation for everyday use.
Outward Opening Design: Opening outward saves interior space while maximizing cross-ventilation airflow, which is particularly useful in compact living and working areas.
Project-Specific Customization: Buyers can select from glass upgrades, multiple color families, and screen options to match specific architectural and performance needs.
Customizable Styles
Glass Configuration: Standard 5+27A+5 double tempered glass; upgradeable to Low-E, laminated, triple, tinted, reflective, or frosted options per project requirement.
Frame Depth and Profile: Available within the 109/118/127 mm family range with 1.8-2.0 mm profile thickness depending on the selected series.
Size and Layout: Options include single sash, split fixed/operable, three-section, upper/lower fixed, or bay-style combinations for custom casement window projects.
Color and Finish: Choices include Pearl White, Quartz Gray, Starry Sky Black, wood grain finishes, and custom PVDF colors with applicable upcharges.
Opening Direction: Outward left or right, awning configuration, or inward tilt-turn alternate for tall openings, confirmed per project.
Hardware Accessories
Handle: WEHAG handle available in black or silver finish, matched to the selected series for consistent aesthetics and reliable operation.
Hinge: WEHAG hinge engineered to support large sash load requirements and sustained outward operation cycles.
Lock: Two-point or six-point black lock selected by series, providing multi-point security locking for enhanced protection.
Limiter: Optional simple limiter or safety casement limiter available for controlled opening range and child safety.
Screen: Optional anti-theft, 304 high-definition mesh, diamond mesh, or 48-mesh high-transparency screen to suit different ventilation needs.
Basic Parameters
Performance Item | Available Information | Buyer Notes |
|---|---|---|
Thermal Insulation | U-Factor 0.23 | Confirm glass configuration and whether Low-E is included to achieve this value. |
Wind Pressure Resistance | 5 KPa | Must confirm against project wind load requirements and local building code. |
Water Tightness | 700 Pa | Target high-performance spec; confirm by final series and test report. |
Air Tightness | 1.2 m3/(m.h) | Target spec; confirm by final series and applicable testing standard. |
Sound Insulation | 35 dB | Target with double glass; confirm if upgraded glass is needed for higher rating. |
Product Specifications
Specification | Details |
|---|---|
Nominal Size | 24 x 72 in (610 x 1829 mm) |
Approximate Area | 1.12 m2 |
Frame Depth | 109/118/127 mm (family range, confirm by series) |
Profile Thickness | 1.8-2.0 mm (2.0 mm stated, confirm by series) |
Glass Configuration | 5+27A+5 mm double tempered insulated with argon |
Spacer | PVDF aluminum |
Opening Method | Outward opening / awning |
Frame Material | Thermal-break 6063-T5 aluminum |
Insulation Strip | PA66 |
Matched Family | S9 / WY-127 / 109-118 mm high-performance casement |
Customization | Available upon request; final specifications confirmed at procurement stage |
Advantages
Project-Grade Aluminum Frame: Thermal-break 6063-T5 aluminum frame engineered specifically for large custom casement window openings in commercial and residential builds.
Structural Split-Panel Safety: Engineered split-panel option ensures structural safety and code compliance for tall 24x72 inch sizes.
Reliable Hardware Integration: WEHAG hardware system designed for secure and smooth large-sash outward operation, reducing operational strain.
Flexible Glass Upgrades: Multiple glass upgrade options support project-specific thermal, sound, and safety targets for diverse environments.
Architectural Customization: Extensive color and style customization supports diverse architectural and project design needs seamlessly.
Application Scenarios
Apartment: Suitable for apartment living rooms and bedrooms where outward opening saves interior space while providing ventilation and natural light through tall openings.
Home Office: Provides daylight and airflow for home office spaces; the thermal-break frame supports comfortable indoor temperature during working hours.
Hotel: Fits hotel guestroom facades requiring sound insulation, energy performance, and outward operation for guest safety and controlled ventilation.
Office Building: Supports commercial office facades needing thermal performance and air tightness; the split-panel option accommodates tall window openings in office environments.
Outdoor: Suitable for outdoor-facing enclosures and balcony connections; buyers should confirm weather resistance, water tightness, and surface finish for exposure conditions.
Residential Building: Fits residential building exteriors requiring custom large-size casement windows with engineered hardware and project-specific wind load compliance.
Exterior: Integrates into exterior facade systems with multiple color and glass options; buyers must confirm wind pressure, water tightness, and installation conditions.
Villa: Appropriate for villa projects demanding custom colors, wood grain finishes, and high-performance glass packages for luxury residence aesthetics.
Inquiry Guidance
To request a quote, please share your project location, required size, quantity, preferred frame color, glass type, hardware requirements, and drawings or reference photos if available.
FAQ
How do I get a quote for a 24x72 casement window?
Provide rough opening dimensions, project location, opening direction, desired glass package, and color. The supplier confirms the series, split layout, and final pricing based on these project details.
Is a single sash or split layout required for the 24x72 size?
A split layout combining fixed and operable sections is recommended for this tall size. A single sash may be possible only after hinge and load engineering confirmation.
What glass upgrades are available for this window?
Upgrades include Low-E, laminated, triple, tinted, reflective, frosted, and bullet-proof options. Your selection directly impacts the U-Factor, SHGC, and sound insulation ratings.
What certifications apply to this product?
The brand holds NFRC, CE, AS2047, CSA, and ISO9001 certifications. Applicability to the specific product series must be confirmed per project and target market.
What is the minimum order quantity and lead time?
An indicative MOQ from platform listings is 2 m2 with customization. Lead time reference is approximately 25 days. Both MOQ and lead time must be confirmed per order.
How is the window packaged for export shipping?
Export packaging includes wooden-frame packaging, protective tape, pallet fixing, plastic belts, PE films, and air bags between pallets for sea freight protection.
What information is needed before ordering?
Buyers should provide exact rough opening, floor level, wind load code, opening direction, glass package, color, and whether split panels are acceptable before production.
