A 2x3 casement window provides controlled ventilation through hand-crank operation, built with a 6063-T5 aluminum thermal-break frame and double tempered glass for B2B project buyers.
- Frame depth options of 72 mm, 86 mm, or 100 mm to match structural needs
- EPDM rubber strip sealing for verified weather resistance
- Made-to-size manufacturing within W450-800 x H600-1500 mm range
Product Details
The 2x3 casement window utilizes a 6063-T5 aluminum profile with 1.4 mm wall thickness and EPDM rubber strip sealing. Unlike standard push-out or sliding units, the hand-crank mechanism allows precise airflow control and is easier to operate in hard-to-reach installations.
Buyers can select from WY-72, WY-86, or WY-100 series based on project requirements. WY-72 features an American crank with 5+27A+5 mm glass, while WY-86 and WY-100 use an Australian hanging crank. The 610x914 mm nominal size fits within the cranked-out opening panel range, supporting various thermal and acoustic needs.
Product Features
Hand-Crank Operation: Enables precise ventilation control and easy access for hard-to-reach placements, offering a practical crank out window mechanism for various interior layouts.
Aluminum Thermal-Break Frame: 6063-T5 aluminum window profiles in 72, 86, or 100 mm depths adapt to different climate zones and structural requirements.
Double Tempered Glass: Configurable with 5+27A+5 or 5+15A+5 mm packages, providing safety and thermal performance with available Low-E and argon upgrades.
EPDM Rubber Sealing: Delivers verified water resistance at 350 Pa and air tightness at 4.5 m3/(m·h) for reliable weather protection in exposed locations.
Configurable Safety Screens: Includes anti-theft, 304 high-definition mesh, diamond mesh, and 48-mesh high-transparency options subject to series compatibility.
Made-to-Size Manufacturing: Supports project-specific dimensions within W450-800 x H600-1500 mm, ensuring a custom aluminum window fit for diverse building openings.
Customizable Styles
Opening Style: Single casement, awning, or fixed and operable composite layouts available to match room layout and airflow preferences.
Glass Package: Double tempered 5+27A+5 or 5+15A+5 mm, with argon, warm-edge, Low-E, laminated, triple, or blind-glass upgrades.
Frame Depth: Select 72 mm, 86 mm, or 100 mm profiles based on structural requirements and desired thermal break casement window performance.
Color Finish: 12 standard families including Pearl White and Black Walnut wood grain; PVDF and custom colors available with upcharges.
Sash Configuration: Single sash, double sash, side-opening with center fixed, three-segment, or irregular stepped and hexagonal combinations.
Hardware Accessories
Hand Crank: American hand crank for WY-72 series, Australian hanging hand crank for WY-86 and WY-100, matched to each mechanism.
Lock Seat: Multi-point switch lock seat for WY-72, or single-point switch lock seat for WY-86 and WY-100 series security.
Casement Limiters: Simple limiter or safety limiter options available for controlled opening range and enhanced ventilation management.
Screen Options: Anti-theft screen, 304 high-definition mesh, diamond mesh, and 48-mesh high-transparency mesh, subject to series compatibility.
Optional Add-ons: Outward top-hung hardware, handle upgrades, and fixed or opening safety fences available for enhanced project security.
Basic Parameters
Performance Item | Available Information | Buyer Notes |
|---|---|---|
Thermal Insulation | U-Factor 0.39 | Verify U-Factor applies to selected glass package; argon and warm-edge upgrades available. |
Wind Pressure Resistance | 5 KPa | Verify this meets local wind load requirements for installation height and zone. |
Water Tightness | 350 Pa | Confirm if this meets local building code requirements for the project location. |
Air Tightness | 4.5 m3/(m·h) | Confirm air leakage class rating applicable to project market standards. |
Sound Insulation | 30 dB | Confirm if acoustic performance meets project requirements; glass upgrades available. |
Product Specifications
Specification | Details |
|---|---|
Nominal Size | 24 x 36 in (610 x 914 mm) |
Frame Material | 6063-T5 aluminum profile |
Frame Depth Options | 72 mm / 86 mm / 100 mm |
Profile Thickness | 1.4 mm |
Sealing | EPDM rubber strip |
Glass (WY-72/WY-100) | Double tempered 5+27A+5 mm |
Glass (WY-86) | Double tempered 5+15A+5 mm |
Opening Panel Range | W450-800 mm x H600-1500 mm |
Approximate Area | 0.56 m2 |
Opening Method | Flat opening / hanging up, hand-crank operation |
Advantages
Frame Depth Options: Three selectable depths (72/86/100 mm) allow buyers to match thermal and structural requirements per project.
Operational Flexibility: Hand-crank operation provides controlled ventilation and is suitable for hard-to-reach window placements.
Glass Configurations: Double tempered glass with argon, warm-edge, and Low-E upgrades supports varying climate needs.
Color Customization: Twelve standard color families plus PVDF and wood grain finishes offer design flexibility.
Export Packaging: Wooden frames, PE films, and air bags support sea freight for international project shipping.
Application Scenarios
Apartment: Compact footprint and crank operation maximize usable interior space while delivering efficient airflow for urban living environments.
Home Office: Double tempered glass and EPDM sealing help reduce exterior noise, supporting a quieter workspace with natural light.
Hotel: Guest comfort is supported by controlled ventilation and weather resistance; hardware options can be tailored to hospitality standards.
Office Building: Thermal-break aluminum frames and configurable glass packages contribute to energy efficiency and lower maintenance requirements.
Outdoor: For outdoor-facing enclosures, buyers should confirm water tightness and weather resistance against local exposure conditions.
Residential Building: Safety limiters, mesh screens, and secure lock seats provide practical protection for family-occupied residential spaces.
Exterior: Wind resistance and facade integration should be verified by buyers against project-specific structural and architectural codes.
Villa: Extensive color customization and wood grain finishes allow design coordination for distinctive architectural and interior styling.
Inquiry Guidance
To request a quote, please share your project location, required size, quantity, preferred frame color, glass type, hardware requirements, and drawings or reference photos if available.
FAQ
How do I request a quote for the 2x3 casement window?
Provide drawings or a window schedule, selected series (WY-72/86/100), glass package, color, hardware, and screen preferences. DERCHI confirms price after drawing review.
Which series should I choose: WY-72, WY-86, or WY-100?
Selection depends on frame depth, glass package, and hardware style. WY-72 uses an American crank with 5+27A+5 glass, while WY-86 and WY-100 use an Australian crank.
What glass upgrades are available for this window?
Argon fill, warm-edge spacer, Low-E, laminated, triple, and blind-glass options are available. These upgrades directly affect the U-Factor and SHGC values.
Can I customize the opening direction and sash configuration?
Yes, single sash, double sash, fixed and operable composites, and irregular shapes are available. The final layout and crank side are confirmed during quotation.
What safety options are offered for this product?
Safety limiters, fixed or opening safety fences, anti-theft screens, and multiple mesh types are available. Compatibility varies by selected series.
How is the product packaged for export shipping?
Windows use wooden-frame packaging with protective tape, pallet fixing, plastic belts, PE films against sea water, and air bags placed between pallets.
Do you provide certifications or test reports?
Buyers should request applicable test reports for their specific market and project. Do not assume certification coverage without verifying with the supplier first.
