A 30 inch casement window provides an outward-opening, made-to-measure glazing solution for B2B residential and commercial projects. Built with thermal-break 6063-T5 aluminum, it pairs insulated argon glass with WEHAG hardware to support energy efficiency and ventilation needs.
- Thermal-break 6063-T5 aluminum frame with PA66 insulation strip
- 5+27A+5 mm double tempered insulated glass with argon and PVDF spacer
- WEHAG handle and hinge with two-point or six-point locking options
- Multiple customizable series families for different performance tiers
Product Details
The structure of this 30 inch casement window centers on a thermal-break 6063-T5 aluminum frame, available in 109, 118, or 127 mm depths depending on the selected series. A PA66 insulation strip separates the interior and exterior aluminum profiles, reducing thermal transfer more effectively than non-thermal-break frames. The standard 5+27A+5 mm double tempered insulated glass includes argon gas and a PVDF aluminum spacer, supporting the target energy efficiency and sound insulation values.
As an outward opening casement window, the sash swings outward to preserve interior floor space, making it suitable for kitchens, bathrooms, and compact rooms. Multiple series families, including WY-72, WY-100, WY-86, S9, and WY-127, address different project tiers and structural requirements. Because the nominal height is missing from the 30-inch (762 mm) width reference, buyers must provide the full height dimension to confirm the final series selection and performance parameters.
Product Features
Thermal-Break Aluminum Frame: The 6063-T5 frame with PA66 strips reduces conductive heat transfer, supporting energy efficient casement window targets for exterior building envelopes.
Double Tempered Insulated Glass: The 5+27A+5 mm argon-filled unit with a PVDF spacer helps manage indoor temperatures and targets a 35 dB sound insulation rating.
Outward Opening Design: Hinges allow the sash to swing outward, saving interior space and avoiding interference with curtains, fixtures, or furniture in compact rooms.
WEHAG Hardware System: WEHAG handles and hinges provide smooth operation, while two-point or six-point locks enhance forced-entry resistance for occupant security.
Glass Upgrade Options: Buyers can specify Low-E, laminated, triple, tinted, reflective, frosted, or bullet-proof glass to meet specific acoustic, solar, or safety requirements.
Made-to-Measure Production: Custom aluminum casement window dimensions are manufactured to project specifications, accommodating unique architectural openings and design requirements.
Customizable Styles
Glass Configuration: Base 5+27A+5 double tempered with argon; upgrade to Low-E, laminated, triple, tinted, reflective, frosted, or bullet-proof glass per project.
Frame Color: 12 color families including Pearl White, Quartz Gray, Starry Sky Black, and wood grain options; PVDF and custom coating upcharges apply.
Sash Style: Single sash, double sash, side-opening with center fixed, three-segment, upper or lower fixed, and irregular or hexagonal combinations available.
Size: Made-to-measure within opening sash limits (W350-750 mm x H400-1600 mm); fixed glass up to 8-12 m2 depending on series.
Screen Options: Anti-theft screen, 304 high-definition mesh, diamond mesh, or 48-mesh high-transparency screen to match ventilation and insect protection needs.
Hardware Accessories
WEHAG Handle: Available in black or silver finish, offering an ergonomic grip for daily operation of the outward opening sash.
WEHAG Hinge: Engineered for smooth outward swing motion and reliable load support for the glazed sash.
Multi-Point Lock: Black two-point or six-point lock depending on series, enhancing security and forced-entry resistance.
Casement Limiter: Optional simple limiter (+60 RMB/pc) or safety limiter (+168 RMB/pc) for controlled ventilation and wind protection.
Safety Accessories: Optional fixed or opening safety fence (+660 RMB/pc) and outward top-hung hardware set (+1650 RMB/set) for specialized configurations.
Basic Parameters
Performance Item | Available Information | Buyer Notes |
|---|---|---|
Thermal Insulation | U-Factor 0.23 (target spec) | Confirm glass package and certification report for selected series. |
Wind Pressure Resistance | 5 KPa (target spec) | Confirm project wind-load requirements and series compliance. |
Water Tightness | 700 Pa (target spec) | Confirm actual tested value for selected series before order. |
Air Tightness | 1.2 m3/(m.h) (target spec) | Confirm test standard and actual value per series. |
Sound Insulation | 35 dB (target spec) | Confirm glass configuration needed to achieve target rating. |
Product Specifications
Specification | Details |
|---|---|
Nominal Width | 30 in (762 mm) |
Nominal Height | To be confirmed (required for series selection) |
Frame Depth | 109 / 118 / 127 mm (by series) |
Profile Thickness | 1.8-2.0 mm depending on series |
Frame Material | Thermal-break 6063-T5 aluminum |
Insulation Strip | PA66 / DERCHI insulation strip |
Glass Configuration | 5+27A+5 mm double tempered insulated with argon |
Glass Spacer | PVDF aluminum spacer |
Opening Mode | Outward opening / awning / cranked-out |
Hardware Brand | WEHAG |
Lock Type | Two-point or six-point (by series) |
Color Options | 12 color families |
Supply Ability | 20,000 m2/month |
Advantages
Thermal-Break Construction: The 6063-T5 aluminum frame with PA66 strips reduces heat transfer, supporting energy-efficient building envelope requirements.
Made-to-Measure Flexibility: Custom dimensions and sash configurations accommodate project-specific openings and architectural design requirements.
Multiple Series Families: WY-72, WY-100, WY-86, S9, and WY-127 address different performance tiers and budget levels for flexible project matching.
Export-Grade Packaging: Wooden frames, protective tape, pallet fixing, PE films, and air bags support safe sea freight transit.
Custom Project Support: Backed by a 70,000 m2 facility with 600 employees and 100+ patents, providing experienced manufacturing capacity.
Application Scenarios
Apartment: The 30-inch width suits urban apartment bedrooms and kitchens where interior space is limited; outward opening avoids obstructing interior layouts.
Home Office: Thermal-break frame and insulated glass help maintain comfortable indoor temperatures for productive work-from-home environments.
Hotel: WEHAG hardware and multi-point locking support guest room security; customizable finishes match diverse interior design themes.
Office Building: Multiple series families with target wind pressure and water tightness ratings suit commercial facade requirements.
Outdoor: Outward-opening design and optional safety limiters provide controlled ventilation for outdoor-facing enclosures; buyers should confirm weather resistance and installation conditions.
Residential Building: Made-to-measure sizing and 12 color families support diverse residential project specifications and architectural styles.
Exterior: Thermal-break 6063-T5 aluminum frame with argon-filled double glass targets energy efficiency for exterior facade applications; confirm water tightness and surface finish.
Villa: Glass upgrades including Low-E and laminated options, plus wood-grain finishes, support high-end villa project requirements and aesthetic preferences.
Inquiry Guidance
To request a quote, please share your project location, required size, quantity, preferred frame color, glass type, hardware requirements, and drawings or reference photos if available.
FAQ
How do I get a quote for a 30 inch casement window?
Provide window height, quantity, glass preference, color, project location, and applicable wind-load standard. Height is required for final series selection. Request a formal quote for current pricing.
Why is window height needed for a quote?
Series selection depends on both width and height. The 30-inch width alone cannot confirm the final product family or performance parameters. Providing height allows accurate model matching.
What customization options are available?
Glass upgrades, 12 color families, sash styles, screen options, and safety accessories are customizable per project. Confirm specific configurations and applicable upcharges during quotation.
Are the listed performance values confirmed?
Listed values are target specs. Actual tested values require per-series verification and certification reports. Buyers should request test documentation for their selected configuration.
How are the windows packaged for shipping?
Windows use wooden-frame packaging with protective tape, pallet fixing, plastic belts, PE films against sea water, and air bags between pallets for secure sea freight.
What is the lead time for orders?
Indicative lead time is 25-35 days per official commercial terms. Confirm exact timeframes per order volume and customization scope during the formal quotation process.
Which certifications apply to this product?
NFRC, CE, AS2047, CSA, and ISO9001 are cited globally. Buyers should confirm whether specific certification documents apply to the selected product configuration and target market.
