Product Details
This aluminum sliding glass door delivers verified Grade 8 wind resistance and Grade 6 air tightness, making it a reliable choice for sliding glass door contractors seeking data-backed performance. The patented hidden nine-step ladder drainage and ground-leakage system prevent water backflow without exposed holes, while the 5+27A+5 insulated glass with inert gas fill resists condensation. For sliding glass door contractors prioritizing installation speed, the 90° screw connection simplifies assembly.
Typhoon-resistant anti-sway wheels prevent sash detachment during severe wind events
POK material silent four-wheel pulley ensures smooth, quiet daily operation
Curved top option available for architectural design flexibility
Product Features
Ultra-thick Insulated Glass: The 5+27A+5 insulated glass unit is injected with inert gas to prevent fogging and condensation, featuring a fluorocarbon aluminum spacer resisting yellowing. Sliding glass door contractors should confirm glass thickness requirements for specific project energy codes.
Typhoon-resistant Anti-sway System: Upper anti-sway wheels prevent the sash from swaying or detaching during high-wind events, supporting the Grade 8 wind resistance rating at 4.5 kPa. Exterior sliding glass door contractors in storm-prone regions should verify local building code compliance.
Patented Hidden Drainage: The hidden nine-step ladder design and ground-leakage drainage prevent backflow and drain quickly without exposed holes. This patented structure enhances water management and aesthetics, which sliding glass door contractors value for client-facing installations.
High-strength Corner Connections: Sash connections use full-cavity plastic-wrapped aluminum corner braces for stability, while the outer frame uses 90° screw connections with waterproof gaskets. This push-pull door construction enables easier installation and removal during project assembly.
Enhanced Sealing Design: Sealing wool at the hook cover, embedded sash design, and 12mm upper track overlap significantly improve air and water tightness. Sliding glass door contractors near Long Beach CA and coastal areas should confirm sealing performance against local exposure conditions.
Premium Hardware Configuration: The standard Paige brand aluminum alloy hook lock with anti-slip function, POK silent four-wheel pulley, and 304 stainless steel lock points deliver durable, smooth operation. Hardware colors in silver and black accommodate various project aesthetics for this patio sliding door.
Customizable Styles
Glass Options: Standard 5+27A+5 insulated glass with inert gas and fluorocarbon spacer. Alternative glass configurations may be discussed; sliding glass door contractors should confirm specific energy performance needs with the supplier.
Frame Options: Aluminum frame with 2.2mm wall thickness in two-track (134.5mm) or three-track (204mm) width. Frame color and surface treatment options should be confirmed before ordering.
Size Options: Opening sash ranges from 580–1500mm width and 800–3000mm height. Sliding glass door contractors can specify custom dimensions within these limits for project-specific openings.
Color/Finish Options: Hardware available in silver and black. Frame color options are not specified; buyers should confirm available surface treatments and color selections with the supplier directly.
Track Configuration: Two-track and three-track frame options accommodate different ventilation and screen needs. The three-track version may support the 304 diamond mesh screen for insect protection on this push-pull door.
Curved Top Design: Special manufacturing allows curved top profiles for architectural aesthetics. This option is subject to confirmation of radius specifications and production feasibility with the supplier.
Hardware Accessories
Handle: Paige brand aluminum alloy hook lock and pull handle with oxidized high-gloss bright edge finish. Features anti-slip function for secure operation, available in silver and black to match sliding glass door contractors' project requirements.
Rollers: Custom silent four-wheel pulley made from POK material delivers smooth, quiet sliding. Sliding glass door contractors benefit from reduced maintenance; roller load capacity should be confirmed for oversized panels.
Anti-sway Wheel: Typhoon-resistant upper anti-sway wheel prevents sash swing and detachment during severe weather. Exterior sliding glass door contractors in high-wind zones should verify this component meets local structural requirements.
Lock: 304 stainless steel single hook lock point and seat provide corrosion-resistant security. The Paige one-line lock with anti-slip function ensures the push-pull door stays securely positioned when closed.
Track System: Upper track features 12mm overlap for improved sealing and safety. Frame connections use 90° screws with waterproof gaskets. Sliding glass door contractors should confirm track selection based on screen and panel configuration.
Screen Mesh: 304 stainless steel diamond mesh with 11 mesh count, 0.8mm wire diameter, four-side bending for rigidity. Provides insect protection; compatibility with track configuration should be verified before ordering.
Basic Parameters
Performance Item | Available Information | Buyer Notes |
|---|---|---|
Thermal Insulation | 2.5 W/(m²·K), Grade 5 | Suitable for moderate climates; sliding glass door contractors should confirm compliance with local energy codes. |
Wind Pressure Resistance | 4.5 kPa, Grade 8 | High wind resistance for storm-prone areas; verify test report availability for building approval submissions. |
Water Tightness | 300 Pa, Grade 3 | Handles moderate rain; Exterior sliding glass door contractors should assess site-specific rainfall conditions. |
Air Tightness | 4.5 m³/(m·h), Grade 6 | Strong air sealing; confirm gasket and seal integrity for push-pull door installation projects. |
Sound Insulation | 30 dB, Grade 3 | Basic noise reduction; sliding glass door contractors near Long Beach CA should evaluate if higher grades are needed. |
Product Specifications
Item | Details |
|---|---|
Product Name | Aluminum Sliding Glass Door |
Product Type | Push-pull sliding door for sliding glass door contractors |
Material | Aluminum alloy (Frame: 2.2mm, Sash: 1.8mm wall thickness) |
Glass Type | 5+27A+5 insulated glass with inert gas fill |
Glass Thickness | 5+27A+5 mm (fluorocarbon hollow aluminum spacer) |
Frame Option | Two-track (134.5mm) / Three-track (204mm) |
Hardware | Paige hook lock, POK silent four-wheel pulley, 304 SS lock points |
Opening Style | Horizontal sliding / Push-pull |
Size Range | Opening sash: W 580–1500mm × H 800–3000mm |
Application | Residential, commercial, hospitality projects for sliding glass door contractors |
Customization | Curved top, track config, hardware color (silver/black) |
Notes | Frame colors and test reports available upon request; confirm with supplier |
Advantages
Patented Technology: Three patents cover screen pressing, drainage structure, and hidden stepped drainage. These innovations give sliding glass door contractors verifiable differentiators for client proposals and competitive project bids.
Factory Capability: Production supports two-track and three-track configurations with curved top options. Manufacturing capacity and lead times should be confirmed with the supplier for volume orders.
Structural Performance: Grade 8 wind resistance and Grade 6 air tightness provide measurable benchmarks. Best sliding glass door contractors rely on documented performance data for code compliance and project approvals.
Brand Identification: Deji LOGO on aluminum spacers enhances brand traceability. Exterior sliding glass door contractors can verify product authenticity and quality consistency across project shipments.
Service Capability: OEM and ODM capabilities may be discussed upon request. Sliding glass door contractors near Long Beach CA and other regions should confirm support availability and after-sales terms before ordering.
Customization Capability: Multiple track options, curved top designs, hardware selections, and optional accessories like electric systems and magnetic blinds support diverse requirements for this push-pull door.
Application Scenarios
Apartment: Urban apartment residents need space-saving doors with noise reduction. This aluminum sliding glass door offers 30 dB sound insulation and Grade 5 thermal performance in a slim 60mm sash profile. Sliding glass door contractors should confirm glass and screen configurations for ventilation and building code compliance.
Home Office: Home offices require quiet environments free from external noise. The 30 dB sound insulation combined with silent POK four-wheel pulleys minimizes disruption. Sliding glass door contractors should verify whether enhanced acoustic glass options are available for properties near busy roads.
Hotel: Hotels need doors combining aesthetics, durability, and guest comfort. The hidden drainage maintains clean sightlines while inert gas-filled glass prevents fogging. Sliding glass door contractors supplying hospitality projects should confirm finish options and hardware selections to match interior design requirements.
Office Building: Commercial offices demand weather-resistant entrances with reliable operation. Grade 8 wind resistance and 304 stainless steel hardware resist corrosion in high-traffic installations. Sliding glass door contractors should confirm compliance with commercial building codes for this push-pull door application.
Outdoor: Outdoor installations face direct weather exposure requiring robust water and wind management. Patented drainage and typhoon-resistant anti-sway wheels address these challenges. Exterior sliding glass door contractors must confirm water tightness grades, surface finish durability, and installation conditions meet site-specific requirements before ordering.
Residential Building: Residential projects balance energy efficiency, security, and ease of operation. Grade 5 thermal insulation and 304 stainless steel lock points address these priorities. Sliding glass door contractors near Long Beach CA should verify performance grades satisfy local residential building standards and homeowner requirements.
Exterior: Exterior-facing doors demand high weather resistance and structural stability. Grade 8 wind resistance and ground-leakage drainage manage severe conditions. Exterior sliding glass door contractors should confirm wind pressure requirements, water tightness ratings, surface treatment longevity, and proper installation methods for each project's exposure level.
Villa: Villa projects feature large openings and architectural details like curved tops. This aluminum sliding door supports heights up to 3000mm with curved top options. Best sliding glass door contractors should confirm frame colors and premium hardware selections to match luxury aesthetic expectations.
Request a Quote
To request a precise quotation for this aluminum sliding glass door, provide your project specifications using the checklist below. Whether you are among Exterior sliding glass door contractors or sliding glass door contractors near Long Beach CA, submitting complete details ensures accurate pricing and production planning. Contact the supplier to discuss configuration options and receive a tailored project proposal.
Product title and required quantity
Opening dimensions (width × height)
Track configuration (two-track or three-track)
Glass and frame color requirements
Hardware color preference (silver or black)
Target market and destination port
Certification or test report requirements
Project drawings if available
What to Confirm Before Ordering
Frame Color Options: Only hardware colors (silver, black) are specified; available frame surface treatments and color selections should be confirmed with the supplier before ordering.
Test Reports: Official test report numbers and certifying bodies are not listed; request certified documentation for building permit and compliance submissions.
MOQ and Lead Time: Minimum order quantities and production timelines are unspecified; confirm these details before committing to project schedules.
Warranty Terms: Warranty coverage and duration are not stated; clarify after-sales support and guarantee terms during the quotation process.
OEM/ODM Needs: Custom branding or design modifications are unconfirmed; discuss partnership flexibility if applicable to your distribution or project requirements.
Compliance and Documentation Notes
Performance grades are documented for wind resistance, air tightness, water tightness, thermal insulation, and sound insulation. However, official test report numbers and certifying bodies are not provided in current specifications. Sliding glass door contractors requiring compliance documentation for building permits should explicitly request certified test reports during the quotation process. Certification applicability varies by target market; confirm whether available documentation satisfies regional building code requirements for your specific project location.
FAQ
Why do sliding glass door contractors choose this door for storm-prone regions?
The door features Grade 8 wind resistance at 4.5 kPa and typhoon-resistant anti-sway wheels that prevent sash detachment during high winds. Sliding glass door contractors should verify these ratings meet local building code requirements for their specific project locations.
How does the patented drainage system work?
The hidden nine-step ladder design creates multiple barriers against water infiltration, while ground-leakage drainage prevents backflow and drains quickly without exposed holes. Exterior sliding glass door contractors should confirm this system meets site-specific rainfall management needs.
What glass configuration is standard on this push-pull door?
Standard configuration is 5+27A+5 insulated glass with inert gas fill and a fluorocarbon aluminum spacer that resists yellowing. This prevents fogging and condensation. Sliding glass door contractors can discuss alternative glass options for specific thermal or acoustic project needs.
What size openings can this aluminum sliding door accommodate?
Opening sash dimensions range from 580–1500mm in width and 800–3000mm in height. Curved top designs are also available. Sliding glass door contractors should provide project-specific opening dimensions for accurate manufacturing and installation planning.
Is the screen mesh included with this patio sliding door?
The 304 stainless steel diamond mesh screen with 11 mesh count and 0.8mm wire diameter is available. Screen compatibility depends on track configuration. Best sliding glass door contractors should confirm track type and screen requirements before placing orders.
What lock and security features are standard?
Standard configuration includes a Paige brand aluminum alloy hook lock with anti-slip function and 304 stainless steel single hook lock points. Hardware is available in silver and black. Buyers requiring keyed lock options should discuss the Beethoven lock upgrade with the supplier.
Are test reports available for building code compliance?
Performance grades are documented for wind, air tightness, thermal, water, and sound insulation. However, official test report numbers and certifying bodies should be confirmed with the supplier for project submission and building approval requirements.
Can sliding glass door contractors near Long Beach CA order custom configurations?
Custom options including curved tops, track configurations, and hardware colors may be available. Contractors should confirm frame color selections, surface treatments, OEM requirements, and minimum order quantities with the supplier before finalizing specifications.
What optional accessories are available for this door?
Optional accessories include 26A magnetic controlled blinds, 27A electric system, Yunhua floating fittings, and frame wrap options. Exterior sliding glass door contractors should verify accessory compatibility with selected track and panel configurations before ordering.
